Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors*M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**AMD X870E ChipsetM.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)4 x SATA 6Gb/s ports*AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10. RAID 5 Function is only supported by AMD Ryzen 9000series CPU.** PCIEX16(G5)_2 slot shares bandwidth with M.2_2.
Graphics
1 x HDMITM port** 2 x USB4 (40Gbps) ports support USB Type-C display outputs*** * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.** Supports 4K@60Hz as specified in HDMI 2.1. *** Supports max. 8K@60Hz as specified in DisplayPort 1.4.**** Output at USB4_EC1 and USB4_EC2, each requires a USB-C to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution.
Sound card
Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* Impedance detection for front and rear headphone outputs Internal audio amplifier to enhance the highest sound quality for headphones and speakers Supports: jack detection, streaming, front panel jack repurposing High quality stereo playback output SNR 120 dB and recording input SNR 113 dB (line in) Supports up to 32-bit/192 kHz playback* Audio features Audio shielding Premium audio capacitors Dedicated PCB audio layers Unique de-pop circuit * Due to HDA bandwidth limitations,32-bit/192 kHz is not supported for 7.1 surround sound.** A chassis with an HD audio module on the front panel is required to support 7.1 surround audio output.
Network interface
Wi-Fi 802.11a/b/g/n/ac/ax/be
Network interface
1 x 10/100/1000/2500 Mbit/s
Network interface
1 x 10/100/1000 Mbit/s
Network interface
Bluetooth
Network interface
Ethernet 1 x Marvell AQtion 10Gb Ethernet 1 x Intel 2.5Gb Ethernet ASUS LANGuard Wireless & Bluetooth Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6 GHz frequency band** Supports Wi-Fi 7 320 MHz band, up to 6.5 Gbps transfer speed. Bluetooth v5.4*** *Wi-Fi features may vary by OSFor Windows 11, Wi-Fi 7 will require version 24H2 or later for full functionality, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.For Windows 10, please note that there is no driver available, please refer to the Wi-Fi chipset vendor's website for details.**6GHz Wi-Fi frequency band and bandwidth regulations may vary by country.***Bluetooth version may vary. Please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB ports at back panel
11
USB ports on motherboard
9
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
2
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
11
FireWire (IEEE 1394)
No
COM connector / port
Yes
LPT connector / port
No
External connectors
2 x USB4 Type-C
External connectors
1 x DisplayPort
External connectors
1 x HDMI
External connectors
1 x Side Speaker
External connectors
1 x Rear Speaker
External connectors
1 x Line Out (front)
External connectors
1 x MIC (front)
External connectors
2 x RJ-45
External connectors
1 x USB 2.0
External connectors
1 x USB 3.1 Type-C
External connectors
7 x USB 3.1
External connectors
1 x Przycisk Clear CMOS
External connectors
1 x Flash BIOS Button
Onboard connectors
4 x SATA III 6Gb/s
Onboard connectors
3 x USB 2.0/1.1 header
Onboard connectors
1 x Serial port header
Onboard connectors
1 x System panel header
Onboard connectors
1 x 4-pin water-pump-fan
Onboard connectors
1 x 24pin ATX zasilanie
Onboard connectors
4 x M.2
Onboard connectors
1 x 4pin wentylator OPT CPU
Onboard connectors
5 x 4pin Chassis fan
Onboard connectors
1 x 8pin 12V power
Onboard connectors
1 x USB 3.0 header
Onboard connectors
1 x USB C
Onboard connectors
1 x 4pin CPU fan
Onboard connectors
1 x Front panel audio header
Onboard connectors
1 x Chassis intrusion header
Onboard connectors
1 x Thermal sensor connector
Onboard connectors
1x CPU/DRAM overvoltage jumper
Onboard connectors
3 x Addressable LED
BIOS
256 Mb Flash ROM, UEFI AMI BIOS
Form factor
ATX
Dimensions
30.5 cm x 24.4 cm
Accessories included
DisplayPort Cable 4 x SATA 6Gb/s Cables Extra Cooling Kit Thermal Pad for M.2 22110 Q-ASUS WiFi Antenna Q-Connector Q-Latch M.2 Pack Q-Latch Q-Slide M.2 Pack for M.2 Backplate 2 x Rubber Packs for M.2 ProArt Ruler Quick Guide ACC Express Activation Key Card
Supported operating systems
Windows 11
Software
ASUS Exclusive SoftwareArmory Crate- Aura Creator- Aura Sync- Fan Xpert 4 with AI Cooling II- Power SavingASUS DriverHubASUS GlideXUSB Wattage WatcherTurboV CoreASUS CPU-ZProArt Creator HubCreationFirstAdobe Creative Cloud (Free Trial)Norton 360 Deluxe (60 Days Free Trial)WinRAR (40 Days Free Trial)UEFI BIOSASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ ModeFlexKey
