CPU:- 1 x Blazing M.2 Socket (M2_1, Key M), supports 2280 PCIe Gen5x4 mode (128 Gb/s)*Chipset:- 1 x Hyper M.2 Socket (M2_2, Key M), supports 2280 PCIe Gen4x4 mode (64 Gb/s)*- 1 x Hyper M.2 Socket (M2_3, Key M), supports 2280 PCIe Gen4x4 mode (64 Gb/s)*- 1 x Hyper M.2 Socket (M2_4, Key M), supports 2280 PCIe Gen4x4 mode (64 Gb/s)*- 6 x SATA3 6.0 Gb/s Connectors* Supports NVMe SSDs as boot drivesM2_1 is the first priority for M.2 installation.The M2_1 will run on the Gen5x4 platform with 9000 and 7000 series processors and on the Gen4x4 platform with 8000 series processors (Phoenix 1 and Phoenix 2).
Graphics
AMD RDNA Integrated Graphics (Actual support may vary by CPU) 1 x HDMI 2.1 TMDS/FRL 8G Compatible, Supports HDR, HDCP 2.3 and Max Resolution up to 4K 120Hz 2 x USB4, Supports HDCP 2.3 and Max Resolution up to 8K 30Hz* *Only CPU built-in graphics can be displayed via USB4 ports. If you want to display on a Type-C monitor, please use AM5 Ryzen 9000, 8000 and 7000 processors with built-in graphics.
Sound card
5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec) WIMA Audio Capacitors (For Rear Outputs) ESS SABRE9219 DAC for Rear Panel Audio (130dB SNR) Individual PCB Layers for R/L Audio Channel Direct Drive Technology on Front headphone port (Supports up to 600 Ohm headsets) Nahimic Audio
Network interface
Bluetooth
Network interface
Wi-Fi 802.11a/b/g/n/ac/ax/be
Network interface
1 x 10/100/1000/2500/5000 Mbit/s
Network interface
LAN 5 Gigabit LAN 10/100/1000/2500/5000 Mb/s Realtek RTL8126 Wireless LAN 802.11be 2x2 Wi-Fi 7 Module Supports IEEE 802.11a/b/g/n/ac/ax/axe/be Supports 2.4GHz/5GHz/6GHz* frequency band Supports 160MHz channel bandwidth with 6GHz* frequency band 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology Supports Bluetooth 5.4 Supports MU-MIMO
USB ports at back panel
12
USB ports on motherboard
9
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
7
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
8
FireWire (IEEE 1394)
No
COM connector / port
No
LPT connector / port
No
External connectors
1 x S/PDIF
External connectors
1 x Line Out
External connectors
2 x SMA
External connectors
5 x USB 3.1
External connectors
2 x USB4 Type-C
External connectors
3 x USB 3.0
External connectors
2 x USB 2.0
External connectors
1 x RJ-45
External connectors
1 x HDMI
External connectors
1 x Line In
External connectors
1 x Przycisk Clear CMOS
External connectors
1 x USB BIOS Flashback button
Onboard connectors
2 x 4pin wentylator CPU
Onboard connectors
1 x Reset button
Onboard connectors
1 x Thermistor Cable Header
Onboard connectors
1 x Power button
Onboard connectors
1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors
4 x 4pin Chassis fan
Onboard connectors
1 x 4-pin water-pump-fan
Onboard connectors
2 x 8pin 12V
Onboard connectors
1 x 24pin ATX zasilanie
Onboard connectors
2 x USB 2.0/1.1 header
Onboard connectors
2 x USB 3.0 header
Onboard connectors
1 x USB C
Onboard connectors
1 x System panel header
Onboard connectors
1 x Debug card header
Onboard connectors
1 x RGB LED strip header
Onboard connectors
1 x Power LED and Speaker Header
Onboard connectors
3 x Addressable LED
BIOS
256Mb AMI UEFI Legal BIOS with GUI support
Form factor
E-ATX
Dimensions
30.5 cm x 26.7 cm
Accessories included
4 x SATA Data Cables 1 x ASRock WiFi 2.4/5/6 GHz Antenna 1 x ARGB Splitter Cable 3 x Thermistor Cables
Supported operating systems
Windows 10
Supported operating systems
Windows 11
Software
Software ASRock Motherboard Utility (A-Tuning) ASRock Polychrome SYNC* UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock Auto Driver Installer ASRock Instant Flash
Other information
8-Layer PCB 2oz Copper PCB Certifications FCC, CE ErP/EuP ready (ErP/EuP ready power supply required)
