Supports 3x M.2 slots and 4x SATA 6Gb/s ports* AMD Ryzen 7000 Series Desktop Processors M.2_1 (M-Key) socket, type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_2 (M-Key) socket, type 2242/2260/2280 (supports PCIe 4.0 x4 mode) AMD B650 Chipset M.2_3 (M-Key) socket, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)** 4x SATA 6Gb/s ports * AMD RAID Xpert technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. ** The M.2_3 slot shares bandwidth with a PCIe 4.0 x16 slot (supports x4 mode). When the M.2_3 slot is in PCIe mode, the M.2_3 connector will be disabled.
Graphics
1 x DisplayPort port * 1 x HDMI port ** * Supports up to 8K@60Hz as per DisplayPort 1.4 specification. ** Supports 4K@60Hz as per HDMI 2.1 specification.
Sound card
ROG SupremeFX 7.1 Surround Sound KODEK high-definition audio ALC4080 Impedance measurement for front and rear headphone outputs Supports: jack detection, multi-streaming, front panel jack reassignment High-quality stereo output with 120 dB SNR and 113 dB SNR recording input Supports playback up to 32-bit/384 kHz Audio features SupremeFX shielding technology Savitech SV3H712 amplifier High-quality audio capacitors Audio cover
Network interface
Wi-Fi 802.11a/b/g/n/ac/ax
Network interface
Bluetooth
Network interface
1 x Intel 2.5Gb Ethernet ASUS LANGuard
USB ports at back panel
9
USB ports on motherboard
6
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
1
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
6
FireWire (IEEE 1394)
No
COM connector / port
No
LPT connector / port
No
External connectors
1 x MIC
External connectors
1 x RJ-45
External connectors
2 x SMA
External connectors
4 x USB 2.0
External connectors
3 x USB 3.1
External connectors
2 x USB 3.1 Type-C
External connectors
1 x Central Speaker / Subwoofer
External connectors
1 x Line In
External connectors
1 x Line Out
External connectors
1 x HDMI
External connectors
1 x Side Speaker
External connectors
1 x DisplayPort
External connectors
1 x Flash BIOS Button
Onboard connectors
2 x USB 2.0/1.1 header
Onboard connectors
1 x 24pin ATX zasilanie
Onboard connectors
3 x M.2
Onboard connectors
4 x SATA III 6Gb/s
Onboard connectors
1 x 4pin CPU fan
Onboard connectors
1 x 4pin wentylator OPT CPU
Onboard connectors
1 x 4pin 12V power
Onboard connectors
1 x 8pin 12V power
Onboard connectors
1 x USB 3.0 header
Onboard connectors
1 x USB 3.1
BIOS
256 Mb Flash ROM, UEFI AMI BIOS
Form factor
ATX
Dimensions
30.5 x 24.4 cm
Accessories included
Cables 2 x SATA 6Gb/s cables Additional cooling kit 1 x M.2 thermal pad Other 1 x ASUS Wi-Fi movable antennas 1 x Cable tie pack 1 x M.2 Q-Latch pack 1 x ROG keychain 1 x ROG Strix stickers 1 x ROG Strix thank you card 2 x M.2 rubber packs Documentation 1 x User manual
