CPU: 1 x Blazing M.2 slot (M2_1, Key M), supports 2280 PCIe Gen5x4 (128 Gbps)* mode. 1 x Hyper M.2 slot (M2_2, Key M), supports 2280 PCIe Gen4x4 (64 Gbps) mode*. Chipset: 1 x M.2 slot (M2_3, Key M), supports 2280 PCIe Gen4x2 mode (32 Gbps)* 4 SATA3 6.0Gb/s connectors *Supports booting from NVMe SSD. Supports ASRock U.2 kit
Graphics
Integrated AMD RDNA 2 graphics (Support may vary by CPU) 1 x HDMI 2.1 TMDS/FRL Compatible with 8G, supports HDR, HDCP 2.3 and max. resolutionup to 4K 120Hz
Sound card
7.1 CH HD Audio (Realtek ALC897 Audio Codec) Nahimic Audio
Network interface
1 x 10/100/1000/2500 Mbit/s
USB ports at back panel
12
USB ports on motherboard
6
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
2
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
9
FireWire (IEEE 1394)
No
COM connector / port
No
LPT connector / port
No
External connectors
1 x Line In
External connectors
1 x Line Out
External connectors
1 x MIC
External connectors
1 x RJ-45
External connectors
4 x USB 2.0
External connectors
7 x USB 3.0
External connectors
1 x USB 3.1 Type-C
External connectors
1 x HDMI
External connectors
1 x Flash BIOS Button
Onboard connectors
1 x 4pin CPU fan
Onboard connectors
2 x 8pin 12V
Onboard connectors
1 x 24pin ATX zasilanie
Onboard connectors
2 x USB 2.0/1.1 header
Onboard connectors
1 x USB 3.0 header
Onboard connectors
1 x USB C
Onboard connectors
1 x 4-pin water-pump-fan
Onboard connectors
1 x TPM header
Onboard connectors
1 x Front panel audio header
BIOS
256Mb AMI UEFI Legal BIOS with GUI support
Form factor
ATX
Dimensions
30.5 x 24.4 cm
Accessories included
1 x Operating Instructions 2 x SATA data cables 3 x Screws for M.2 sockets
Supported operating systems
Windows 10
Supported operating systems
Windows 11
Software
Software ASRock Motherboard Utility (Phantom Gaming Tuning) ASRock Phantom Gaming LAN Software ASRock Polychrome SYNC* UEFI ASRock Full HD UEFI ASRock Automatic Driver Installer ASRock Instant Flash
