- Number of Ports
- 8 x 10Base-T/100Base-TX/1000Base-T (1 Gbps) RJ-45</br>2 x (10 Gbps) SFP+
- Switching Protocol
- Ethernet
- Switching Layers
- Layer 2 <br/>Layer 3
- Network/Transport Protocol
- DHCP <br/>IGMP <br/>STP <br/>RSTP <br/>LLDP
- Networking Compliant Standards
- IEEE 802.1X
- Networking Features
- Jumbo Frames Support <br/>6 Ports PoE+ <br/>2 Ports PoE++
- Device Location
- External
- Mounting Capability
- Desktop
- Certifications
- CE, FCC, IC
- LAN
- 8 (RJ-45)
- SFP+
- 2
- Power Supply
- Internal<br/>AC 100-240 V, max 2 A
- Power over Ethernet
- External<br/>DC 44-57 V
- Power Consumption Operational
- 120 W
- Depth (mm)
- 200 mm
- Height (mm)
- 44 mm
- Width (mm)
- 248 mm
- Nominal Weight
- 2.1 kg
- External Color
- White
- Maximum Operating Ambient Temperature
- 45 °C
- Maximum Operating Humidity
- 90 %
- Minimum Operating Ambient Temperature
- -5 °C
- Minimum Operating Humidity
- 10 %
- Warranty Products Returnable
- Yes
- Warranty Term (month)
- 24
- Warranty Validation Criteria
- Serial Number
- Warranty Term Notes
- 24 months - for EU
- Pack Length (mm)
- 365 mm
- Pack Width (mm)
- 84 mm
- Pack Height (mm)
- 260 mm
- Pack Weight Brutto (kg)
- 3 kg
- Pack Weight Netto (kg)
- 2.96 kg
- Pieces in pack
- 1
- Box Length (mm)
- 523 mm
- Box Width (mm)
- 381 mm
- Box Height (mm)
- 300 mm
- Box Weight Brutto (kg)
- 17.756 kg
- Retail Packaging Net Weight Carton
- 0 kg
- Retail Packaging Net Weight Plastic
- 0 kg
- Packs in Box
- 6
- Package Type
- Retail
- EAN Code
- 810084692691
USW-PRO-8-POE-EU
7 Items
Data sheet
- Package type
- Retail
- Power supply
- Internal
AC 100-240 V, max 2 A
- Networking features
- Jumbo Frames Support
6 Ports PoE+
2 Ports PoE++
- Warranty Products Returnable
- Yes
- Warranty Term (month)
- 24
- Warranty Validation Criteria
- Serial Number
- Warranty Term Notes
- 24 months - for EU
- Pieces in pack
- 1
- Box Length (mm)
- 523 mm
- Box Width (mm)
- 381 mm
- Box Height (mm)
- 300 mm
- Retail Packaging Net Weight Carton
- 0 kg
- Retail Packaging Net Weight Plastic
- 0 kg
- Packs in Box
- 6
- Device Location
- External
- Network/Transport Protocol
- DHCP
IGMP
STP
RSTP
LLDP
- Networking Compliant Standards
- IEEE 802.1X
- Certifications
- CE, FCC, IC
- LAN
- 8 (RJ-45)
- SFP+
- 2
- Power Consumption Operational
- 120 W
- Maximum Operating Ambient Temperature
- 45 °C
- Maximum Operating Humidity
- 90 %
- Minimum Operating Ambient Temperature
- -5 °C
- Minimum Operating Humidity
- 10 %
- External Color
- White
- Power over Ethernet
- External
DC 44-57 V
- Mounting Capability
- Desktop
- Number of Ports
- 8 x 10Base-T/100Base-TX/1000Base-T (1 Gbps) RJ-452 x (10 Gbps) SFP+
- Switching Layers
- Layer 2
Layer 3
- Switching Protocol
- Ethernet
Specific References
- EAN13
- 810084692691
- MPN
- USW-PRO-8-POE-EU
