Microphone <br/>LED Indicator <br/>Light Sensor <br/>Reset Button <br/>IR LED for Nightvision <br/>Lock Switch <br/>ARM Cortex A53
External Color
Black
Mounting Capability
Ceiling/Wallmount
Included Accessories
Mount kit
Certifications
CE, FCC, IC
Cable Length
0.3 m
Maximum Operating Ambient Temperature
50 °C
Minimum Operating Ambient Temperature
-30 °C
Maximum Operating Humidity
90 %
Minimum Operating Humidity
0 %
Power Device Type
Power over Ethernet
Maximum Input Voltage
57 V
Maximum Power Consumption
12.5 W
Minimum Input Voltage
37 V
Depth (mm)
100 mm
Height (mm)
95 mm
Width (mm)
100 mm
Nominal Weight
0.55 kg
Warranty Products Returnable
Yes
Warranty Term (month)
12 month(s)
Warranty Validation Criteria
Serial Number
Pack Length (mm)
130.5 mm
Pack Width (mm)
130.5 mm
Pack Height (mm)
152.5 mm
Pack Weight Brutto (kg)
0.877 kg
Pack Weight Netto (kg)
0.5 kg
Pieces in pack
1
Box Length (mm)
467 mm
Box Width (mm)
350 mm
Box Height (mm)
336 mm
Box Weight Brutto (kg)
10.524 kg
Packs in Box
12
Package Type
Box
EAN Code
810177163787
UVC-G6-TURRET-B
2 Items
Data sheet
Cable length
0.3 m
Interface
Ethernet
Camera type
IP Camera
Package type
Box
Focus
Fixed
Maximum video resolution
3840x2160
Warranty Products Returnable
Yes
Warranty Term (month)
12 month(s)
Warranty Validation Criteria
Serial Number
Pieces in pack
1
Box Length (mm)
467 mm
Box Width (mm)
350 mm
Box Height (mm)
336 mm
Packs in Box
12
Data Link Protocol Supports
Fast Ethernet/Ethernet
Certifications
CE, FCC, IC
LAN
1 (RJ-45)
Included Accessories
Mount kit
Maximum Operating Ambient Temperature
50 °C
Maximum Operating Humidity
90 %
Minimum Operating Ambient Temperature
-30 °C
Minimum Operating Humidity
0 %
Built-in Devices
Microphone LED Indicator Light Sensor Reset Button IR LED for Nightvision Lock Switch ARM Cortex A53
Maximum Input Voltage
57 V
Minimum Input Voltage
37 V
Maximum Power Consumption
12.5 W
External Color
Black
Protection Standarts
IP66 IK04
Power Device Type
Power over Ethernet
Mounting Capability
Ceiling/Wallmount
Sensor Resolution
8 Mpixel
Maximum Frame Capture Rate
30 fps
Web Cam Features
Night Vision Face Detection IR Cut Filter Pet Detection Weatherproof Human Detection HDR Vehicle Detection License Plate Recognition 3-axis Manual Adjustments
