Sapphire PULSE AMD RADEON RX9060XT 8GB
- Write a review
€470.66
Tax included
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Guarantee safe & secure checkout
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Honeywell PTM7950 TIM
The Honeywell PTM7950 Thermal Interface Material (TIM) offers a premium solution for high-performance electronics, particularly in the demanding field of graphics processing units (GPUs). The PTM7950 delivers superior thermal conductivity, enhancing the reliability and longevity of graphics cards by its outstanding material characteristics.
AeroCurve Fan Blade
The latest fan blade design builds upon its predecessor with advancements that reduce air friction, increasing the usable fan RPM range while maintaining low noise levels. This refined design ensures improved airflow, optimized static pressure, and enhanced cooling efficiency for demanding applications.
FrameDefense
The mechanical design of the graphics card features a robust, box-like frame that ensures exceptional build quality and durability. This solid construction provides a protective enclosure for all internal components, reducing the risk of damage during handling or installation. This rigid frame offers added stability and strength, making it highly resistant to accidental impacts or pressure, ensuring that the delicate components, such as the GPU, memory, and VRMs, remain secure. With this design, users can confidently handle the card without worrying about compromising its integrity or performance.
Digital Power Design
SAPPHIRE PULSE AMD Radeon™ RX 9060 Series are designed with digital power which provides accurate power control and excellent power efficiency
- GPU: Boost Clock: Up to 3130 MHz
- GPU: Game Clock: Up to 2530 MHz
- Memory: 8GB/128 bit DDR6. 20Gbps Effective
- Stream Processors: 2048
- AMD RDNA™ 4 Architecture
- Ray Accelerator: 32
Manufacturer Website:
https://www.sapphiretech.com/en/consumer/pulse-radeon-rx-9060-xt-8g-m-gddr6
- Category Code
- VGP
- CnCode
- 84718000
- Unit Box Height
- 0.06
- Unit Box Length
- 0.27
- Unit Box Width
- 0.165
- AI accelerators
- 64
- Compute units
- 32
- CUDA
- No
- Graphics processor
- Radeon RX 9060 XT
- Graphics processor family
- AMD
- Infinity cache
- 32 MB
- Maximum displays per videocard
- 3
- Maximum resolution
- 7680 x 4320 pixels
- Parallel processing technology support
- Not supported
- Processor boost clock speed
- 3130 MHz
- Processor boost clock speed (Gaming mode)
- 2530 MHz
- Ray accelerators
- 32
- Stream processors
- 2048
- Data transfer rate
- 20 Gbit/s
- Discrete graphics card memory
- 8 GB
- Graphics card memory type
- GDDR6
- Memory bus
- 128 bit
- DisplayPort version
- 2.1a
- DisplayPorts quantity
- 1
- HDMI ports quantity
- 2
- HDMI version
- 2.1b
- Interface type
- PCI Express x16 5.0
- AMD FreeSync
- Yes
- DirectX version
- 12 Ultimate
- Dual Link DVI
- No
- TV tuner integrated
- No
- Cooling technology
- Sapphire Dual-X
- Cooling type
- Active
- Number of fans
- 2 fan(s)
- Number of slots
- 2
- Product colour
- Grey/White
- Minimum system power supply
- 450 W
- Supplementary power connectors
- 1x 8-pin
- Thermal Design Power (TDP)
- 150 W
- Linux operating systems supported
- Yes
- Minimum RAM
- 8192 MB
- Windows operating systems supported
- Windows 10/Windows 11
- Depth
- 40.6 mm
- Height
- 122 mm
- Length
- 200 mm
- Package type
- Box
- Units per Shipping Box
- 10
- Unit Calculated Volume
- 0.00363 cubm
- Product Net Weight
- 0.7 kg
- Unit Calculated Weight
- 0.873 kg
11350-05-20G
4 Items
Data sheet
- Memory type
- GDDR6 SDRAM
- Package type
- Retail
- Maximum resolution
- 7680x4320
- Warranty Products Returnable
- Yes
- Warranty Term (month)
- 36 month(s)
- Warranty Validation Criteria
- Serial Number
- Pieces in pack
- 1
- Packs in Box
- 10
- Power Consumption Operational
- 170 W
- Cooling System Type
- Dual-X
- Requires Expansion Slot Standard
- PCI Express 5.0 x16
- Video Chipset
- AMD Radeon RX 9060 XT
- Video Memory Type
- Video Controller Memory
- Installed Video Memory Storage Capacity
- 8 GB
- GPU Core Name
- Navi 44
- GPU Core Speed
- 2700 MHz
- GPU Core Speed Boost
- 3290 MHz
- GPU Quantity
- 1
- Stream Processors Quantity
- 2048
- Compute Units Quantity
- 32
- Texture Mapping Unit Quantity
- 128
- Render Output Units Quantity (ROP)
- 64
- Ray-tracing Cores Quantity
- 32
- Max. Monitors Supports
- 3
- 2D/3D Features
- AMD FreeSync
AMD FidelityFX
AMD Radeon Anti-Lag
AMD Software: Adrenalin Edition
AMD Noise Suppression
AMD Infinity Cache
AMD Radiance Display Engine
AMD FidelityFX Super Resolution
AMD RDNA 4 Architecture
AMD F - API Supports
- DirectX 12 Ultimate
- Fill Rate (textures)
- 400.6 GT/s
- Fill Rate (pixels)
- 200.3 GP/s
- Video Memory Speed
- 20 Gbps
- Memory Bus Bandwidth
- 128 bit
- Memory Bandwidth
- 320 GB/s
- HDMI Interface Quantity
- 2
- HDMI Interface Connector Type
- HDMI (Type A)
- DisplayPort Interface Quantity
- 1
- External Power
- 8 pin
- PSU Output Power Required
- 450 W
- Card Slot Width
- 2.3 slot
Specific References
- EAN13
- 4895106297333
- MPN
- 11350-05-20G
