Intel CPU|INTEL|Desktop|Core Ultra|U5-245K|Arrow Lake|4200 MHz|Cores 14|24MB|Socket LGA1851|125 Watts|BOX|BX80768245KSRQCT

Write a review

€277.02

Tax included

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Guarantee safe & secure checkout

245K
Intel Core Ultra 5
14xProcessor cores
Processor socket LGA 1851 (Socket V1)
Processor operating modes 64-bit
Processor cache 24 MB
Package Box
Stepping B0
Processor codename Arrow Lake
Neural processor unit (NPU) Intel AI Boost
Memory channels Dual-channel
On-board graphics card Yes
Market segment Desktop
Intel Core Ultra
U5-245K

Manufacturer Website:
https://ark.intel.com/content/www/us/en/ark/products/241067/intel-core-ultra-5-processor-245k-24m-cache-up-to-5-20-ghz.html

Category Code: CPU
CnCode: 85423190
Unit Box Height: 0.045
Unit Box Length: 0.116
Unit Box Width: 0.102
AI software frameworks supported by CPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
Cooler included: No
Efficient cores: 8
Efficient-core base frequency: 3.6 GHz
Efficient-core boost frequency: 4.6 GHz
Maximum number of DMI lanes: 8
Maximum turbo power: 159 W
Package type: Box
Performance cores: 6
Performance-core base frequency: 4.2 GHz
Performance-core boost frequency: 5.2 GHz
Processor ARK ID: 241067
Processor base power: 125 W
Processor boost frequency: 5.2 GHz
Processor cache: 24 MB
Processor cache type: Smart Cache
Processor codename: Arrow Lake
Processor cores: 14
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Processor model: 245K
Processor operating modes: 64-bit
Processor socket: LGA 1851 (Socket V1)
Stepping: B0
AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
GPU performance up to: 8 TOPs
Neural processor unit (NPU): Intel AI Boost
NPU performance up to: 13 TOPs
Sparsity support: Yes
Total processor performance up to: 30 TOPs
Windows Studio effects support: Yes
ECC: Yes
Maximum internal memory supported by processor: 192 GB
Memory channels: Dual-channel
Memory clock speeds supported by processor: 6400 MHz
Memory types supported by processor: DDR5-SDRAM
Discrete graphics card: No
Discrete graphics card model: Not available
Number of displays supported (on-board graphics): 4
On-board graphics card: Yes
On-board graphics card base frequency: 300 MHz
On-board graphics card DirectX version: 12.0
On-board graphics card dynamic frequency (max): 1900 MHz
On-board graphics card ID: 0x7D67
On-board graphics card model: Intel® Graphics
On-board graphics card OpenGL version: 4.5
On-board graphics card outputs supported: DisplayPort 2.1/Embedded DisplayPort (eDP) 1.4b/HDMI 2.1
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
Xe-cores: 4
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Direct Media Interface (DMI) Revision: 4.0
Embedded options available: No
Execute Disable Bit: Yes
Export Control Classification Number (ECCN): 5A992C
Idle States: Yes
Market segment: Desktop
Maximum number of PCI Express lanes: 24
PCI Express slots version: 4.0/5.0
Scalability: 1S
Supported instruction sets: AVX 2.0/SSE4.1/SSE4.2
Thermal Monitoring Technologies: Yes
Thermal solution specification: PCG 2020A
Use conditions: PC/Client/Tablet/Workstation
Enhanced Intel SpeedStep Technology: Yes
Intel 64: Yes
Intel Trusted Execution Technology: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel vPro® Enterprise Platform Eligibility: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Active Management Technology (Intel® AMT): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Boot Guard: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes
Intel® Hardware Shield Eligibility: Yes
Intel® One-Click Recovery: Yes
Intel® OS Guard: Yes
Intel® Quick Sync Video Technology: Yes
Intel® Remote Platform Erase (RPE): Yes
Intel® Secure Key: Yes
Intel® Speed Shift Technology: Yes
Intel® Stable IT Platform Program (SIPP): Yes
Intel® Standard Manageability (ISM): Yes
Intel® Thread Director: Yes
Intel® Threat Detection Technology (TDT): Yes
Intel® Thunderbolt 4: Yes
Intel® Total Memory Encryption - Multi Key: Yes
Intel® Turbo Boost Technology: 2.0
Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Maximum operating temperature: 105 °C
Harmonized System (HS) code: 8542310050
Launch date: Q4'24
Memory speed (max): 6400 MHz
OpenCL version: 3.0
Status: Launched
Graphics output: DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
L2 cache: 26624 KB
Maximum internal memory: 192 GB
CPU Family name: Intel Core Ultra
Model number: U5-245K
Units per Shipping Box: 5
Unit Calculated Volume: 0.0007488 cubm
Unit Calculated Weight: 0.115 kg

Reference BX80768245K S RQCT

In stock 11 Items

Data sheet

Processor family: Intel Core Ultra 5
L2 cache: 26624 KB
Package type: Box
ECC: Yes
Processor cores: 14
Processor model: 245K
Processor socket: LGA 1851 (Socket V1)
Cooler included: No
Processor boost frequency: 5.2 GHz
Maximum internal memory: 192 GB
Category Code: CPU
CnCode: 85423190
Units per Shipping Box: 5
Harmonized System (HS) code: 8542310050
Market segment: Desktop
Memory channels: Dual-channel
Processor manufacturer: Intel
Model number: U5-245K
Status: Launched
Processor cache: 24 MB
Processor cache type: Smart Cache
Processor generation: Intel Core Ultra (Series 2)
Processor operating modes: 64-bit
Memory clock speeds supported by processor: 6400 MHz
Memory types supported by processor: DDR5-SDRAM
Discrete graphics card: No
Discrete graphics card model: Not available
On-board graphics card: Yes
On-board graphics card model: Intel® Graphics
CPU Family name: Intel Core Ultra
Neural processor unit (NPU): Intel AI Boost
Efficient cores: 8
Efficient-core base frequency: 3.6 GHz
Efficient-core boost frequency: 4.6 GHz
Maximum number of DMI lanes: 8
Maximum turbo power: 159 W
Performance cores: 6
Performance-core base frequency: 4.2 GHz
Performance-core boost frequency: 5.2 GHz
Processor ARK ID: 241067
Processor base power: 125 W
Processor codename: Arrow Lake
Stepping: B0
Maximum internal memory supported by processor: 192 GB
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Direct Media Interface (DMI) Revision: 4.0
Embedded options available: No
Execute Disable Bit: Yes
Export Control Classification Number (ECCN): 5A992C
Idle States: Yes
Maximum number of PCI Express lanes: 24
PCI Express slots version: 4.0/5.0
Scalability: 1S
Supported instruction sets: AVX 2.0/SSE4.1/SSE4.2
Thermal Monitoring Technologies: Yes
Thermal solution specification: PCG 2020A
Use conditions: PC/Client/Tablet/Workstation
Enhanced Intel SpeedStep Technology: Yes
Intel 64: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Boot Guard: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® OS Guard: Yes
Intel® Secure Key: Yes
Intel® Speed Shift Technology: Yes
Intel® Standard Manageability (ISM): Yes
Intel® Thread Director: Yes
Intel® Turbo Boost Technology: 2.0
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Launch date: Q4'24
NPU performance up to: 13 TOPs
Total processor performance up to: 30 TOPs
Maximum operating temperature: 105 °C
Graphics output: DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
OpenCL version: 3.0
Xe-cores: 4
On-board graphics card base frequency: 300 MHz
On-board graphics card dynamic frequency (max): 1900 MHz
AI software frameworks supported by CPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
Sparsity support: Yes
Windows Studio effects support: Yes
Intel Trusted Execution Technology: Yes
Intel® Thunderbolt 4: Yes
Memory speed (max): 6400 MHz
GPU performance up to: 8 TOPs
Number of displays supported (on-board graphics): 4
On-board graphics card DirectX version: 12.0
On-board graphics card ID: 0x7D67
On-board graphics card OpenGL version: 4.5
On-board graphics card outputs supported: DisplayPort 2.1/Embedded DisplayPort (eDP) 1.4b/HDMI 2.1
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
Intel vPro® Enterprise Platform Eligibility: Yes
Intel® Active Management Technology (Intel® AMT): Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes
Intel® Hardware Shield Eligibility: Yes
Intel® One-Click Recovery: Yes
Intel® Quick Sync Video Technology: Yes
Intel® Remote Platform Erase (RPE): Yes
Intel® Stable IT Platform Program (SIPP): Yes
Intel® Threat Detection Technology (TDT): Yes
Intel® Total Memory Encryption - Multi Key: Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes

Specific References

EAN13: 5032037282086
MPN: BX80768245K S RQCT
