AMD
Graphics processor Radeon RX 9060 XT
Memory 16 GB
Graphics card memory type GDDR6
128 bit
PCI Express x16 5.0
2xHDMI
1xDisplay ports
Cooling type Active
Power consumption (typical) 170 W
Manufacturer Website:
https://www.sapphiretech.com/en/consumer/pure-radeon-rx-9060-xt-16g-gddr6
- Category Code
- VGP
- CnCode
- 84718000
- Unit Box Height
- 0.08
- Unit Box Length
- 0.28
- Unit Box Width
- 0.16
- AI accelerators
- 64
- Compute units
- 32
- Graphics processor
- Radeon RX 9060 XT
- Graphics processor family
- AMD
- Maximum displays per videocard
- 3
- Maximum resolution
- 7680 x 4320 pixels
- Processor boost clock speed
- 3290 MHz
- Processor boost clock speed (Gaming mode)
- 2700 MHz
- Ray accelerators
- 32
- Stream processors
- 2048
- Data transfer rate
- 20 Gbit/s
- Discrete graphics card memory
- 16 GB
- Graphics card memory type
- GDDR6
- Memory bus
- 128 bit
- DisplayPort version
- 2.1a
- DisplayPorts quantity
- 1
- HDMI ports quantity
- 2
- Interface type
- PCI Express x16 5.0
- AMD FreeSync
- Yes
- DirectX version
- 12.0
- Dual Link DVI
- No
- OpenGL version
- 4.6
- TV tuner integrated
- No
- Cooling technology
- Sapphire Dual-X
- Cooling type
- Active
- Illumination
- Yes
- Illumination colour
- Multi
- Number of fans
- 2 fan(s)
- Number of slots
- 2
- Product colour
- White
- Minimum system power supply
- 450 W
- Power consumption (typical)
- 170 W
- Supplementary power connectors
- 1x 8-pin
- Linux operating systems supported
- Yes
- Windows operating systems supported
- Windows 10 x64/Windows 11 x64
- Depth
- 124 mm
- Height
- 46.1 mm
- Length
- 240 mm
- Package type
- Box
- Model
- 11350-02-20G
- Units per Shipping Box
- 20
- Unit Calculated Volume
- 0.002625 cubm
- Product Net Weight
- 1 kg
- Unit Calculated Weight
- 0.529 kg
