TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The 10-gigabit ports ensure high-speed data transfer, and their backward compatility with gigabit products reserves room for network upgrades, therefore guarantees stable and long-term usability. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-of-Service (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM function helps facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ 10-gigabit managed switches provide a reliable, secure solution for enterprise, campus and ISP networks.
- 4× 10 Gbps SFP+ slots
- 24× Gigabit 802.3af/at PoE+ ports
- 384 W total PoE budget with up to 30 W PoE output per port*
- Centralized cloud management via the web or the Omada app†
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
- ERPS supports rapid protection and recovery in a ring topology
- Durable metal casing and rack-mountable design
Manufacturer Website:https://www.tp-link.com/en/business-networking/omada-switch-poe/sg3428xmp/- Category Code
- SWI
- CnCode
- 85176200
- Unit Box Height
- 0.1
- Unit Box Length
- 0.53
- Unit Box Width
- 0.44
- Cloud-managed
- Yes
- MIB support
- Yes
- Quality of Service (QoS) support
- Yes
- Switch layer
- L2+
- Switch type
- Managed
- System event log
- Yes
- Web-based management
- Yes
- Basic switching RJ-45 Ethernet ports quantity
- 24
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Console port
- RJ-45/Micro-USB
- Gigabit Ethernet (copper) ports quantity
- 24
- Power connector
- AC-in jack
- SFP+ module slots quantity
- 4
- 10G support
- Yes
- Active link detection
- Yes
- Broadcast storm control
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Flow control support
- Yes
- Head-of-line (HOL) blocking
- Yes
- Link aggregation
- Yes
- Networking standards
- IEEE 802.11d/IEEE 802.1s/IEEE 802.1w
- Number of VLANs
- 4000
- Policy-based routing
- Yes
- Port mirroring
- Yes
- Rate limiting
- Yes
- Spanning tree protocol
- Yes
- Virtual LAN features
- MAC address-based VLAN/Port-based VLAN/Private VLAN/Protocol-based VLAN/Tagged VLAN/Voice VLAN
- VLAN support
- Yes
- Forwarding rate
- 95.23 Mpps
- Jumbo frames
- 9000
- Jumbo frames support
- Yes
- MAC address table
- 16000 entries
- Number of static routes
- 48
- Packet buffer memory
- 12 MB
- Switching capacity
- 128 Gbit/s
- Access Control List (ACL)
- Yes
- BPDU filtering/protection
- Yes
- DHCP features
- DHCP client/DHCP relay/DHCP server/DHCP snooping/DHCPv6 client/DHCPv6 snooping
- IGMP snooping
- Yes
- IP-MAC-Port binding
- Yes
- Loop protection
- Yes
- SSH/SSL support
- Yes
- Multicast support
- Yes
- Management protocols
- SNMPv1/v2c/v3, SNTP
- Form factor
- 1U
- LED indicators
- Yes
- Number of fans
- 2 fan(s)
- Product colour
- Black
- Rack mounting
- Yes
- AC input frequency
- 50/60 Hz
- AC input voltage
- 100 - 240 V
- Power consumption (max)
- 486.2 W
- Power source
- AC
- Power supply included
- Yes
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet plus (PoE+) ports quantity
- 24
- Total Power over Ethernet (PoE) budget
- 384 W
- Heat dissipation
- 1658.78 BTU/h
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- 0 - 45 °C
- Storage relative humidity (H-H)
- 5 - 90 %
- Storage temperature (T-T)
- -40 - 70 °C
- Depth
- 330 mm
- Height
- 44 mm
- Width
- 440 mm
- Cables included
- LAN (RJ-45)
- Quick start guide
- Yes
- Series
- Omada
- Model name
- Omada 24-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 24-Port PoE+
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.02332 cubm
- Unit Calculated Weight
- 5.6 kg
