Dahua NET CAMERA 6MP EYEBALL/IPC-HDW2649TM-S-IL-0280B DAHUA

Dahua NET CAMERA 6MP EYEBALL/IPC-HDW2649TM-S-IL-0280B DAHUA

Write a review

€230.13

Tax included

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Guarantee safe & secure checkout

1/2.7" CMOS image sensor, low luminance, and high definition image
Outputs max. 6 MP (3288×1850) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in warm light and IR LED, the max. IR distance is 30 m and the max. warm light distance is 30 m
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
Supports max. 256 G Micro SD card; built in Mic
12 VDC/PoE power supply, easy for installation

Manufacturer Website:
https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/2-Series/Smart-Dual-Light/IPC-HDW2649TM-S-IL

Category Code: FNC
CnCode: 85258900
Unit Box Height: 0.11
Unit Box Length: 0.14
Unit Box Width: 0.14
Form factor: Turret
Housing material: Metal/Plastic
International Protection (IP) code: IP67
Mounting type: Ceiling/Wall/Pole
Product colour: White
Connectivity technology: Wired
Day/night mode: Yes
Dynamic range: 120 dB
Placement supported: Indoor
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Angle of rotation: 360 °
Camera pan control: Yes
Camera shutter speed: 1/3 - 1/100000 s
Camera tilt control: Yes
Lens viewing angle, diagonal: 132 °
Lens viewing angle, horizontal: 112 °
Lens viewing angle, vertical: 61 °
Minimum illumination: 0.0007 lx
Number of Privacy masking areas: 4
Pan range: 0 - 360 °
Tilt angle range: 0 - 78 °
White balance: Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
Number of sensors: 1
Optical sensor size: 1/2.7 "
Progressive scan: Yes
Sensor type: CMOS
Closest focusing distance: 1 m
Detect distance: 61.2 m
Fixed focal length: 2.8 mm
Fixed focus: Yes
Identify distance: 6.1 m
Maximum aperture number: 1.6
Observe distance: 24.5 m
Recognize distance: 12.2 m
Colour night vision distance: 30 m
LED type: IR
Night vision: Yes
Night vision distance: 30 m
Number of illumination LEDs: 2
Back Light Compensation (BLC): Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Frame rate: 30 fps
Gain control type: Auto/Manual
Highlight Compensation (HLC): Yes
Maximum resolution: 3288 x 1850 pixels
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Region of Interest (ROI) encoding: Yes
Total megapixels: 6 MP
Video compression formats: H.264/H.264B/H.264H/H.265/M-JPEG
Video recording: Yes
Video streaming: Yes
Audio formats supported: G.711 µ-law/G.711 A-law/G.726/PCM
Built-in microphone: Yes
Bluetooth: No
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Networking standards: IEEE 802.1x
Quality of Service (QoS) support: Yes
Streaming method: Multicast
Supported network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, PPPoE, P2P
Wi-Fi: No
Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 256 GB
RAM capacity: 256 MB
ROM capacity: 128 MB
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Human and vehicle targets classification: Yes
IP address filtering: Yes
Mirror: Yes
Network access storage (NAS): Yes
Video motion detection: Yes
DC output voltage: 12
Power consumption (max): 4.6 W
Power consumption (typical): 2.5 W
Power source type: DC,PoE
Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Mobile operating systems supported: Android/iOS
Diameter: 121.9 mm
Height: 99.1 mm
Weight: 530 g
Compliance certificates: CE
Package weight: 670 g
Manual: Yes
Number of cameras: 1
Model: IPC-HDW2649TM-S-IL-0280B
Units per Shipping Box: 20
Unit Calculated Volume: 0.002769 cubm
Unit Calculated Weight: 0.725 kg
