Ubiquiti UDR7 Desktop 10G Cloud Gateway

Write a review

€362.75

Tax included

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Guarantee safe & secure checkout

Desktop 10G Cloud Gateway with integrated WiFi 7, PoE switch, microSD storage, and full UniFi application support.

Manufacturer Website:
https://eu.store.ui.com/eu/en/category/cloud-gateways-wifi-integrated/products/udr7

Category Code: WRO
CnCode: 85176200
Unit Box Height: 0.285
Unit Box Length: 0.154
Unit Box Width: 0.16
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
WLAN data transfer rate (first band): 688 Mbit/s
WLAN data transfer rate (max): 5700 Mbit/s
WLAN data transfer rate (second band): 4300 Mbit/s
WLAN data transfer rate (third band): 5700 Mbit/s
3G/4G USB modem compatibility: No
DSL WAN: No
Ethernet WAN: Yes
SIM card slot: No
Ethernet LAN: Yes
Ethernet LAN data rates: 2500 Mbit/s
Ethernet LAN interface type: 2.5 Gigabit Ethernet
Load balancing system: Yes
Maximum coverage: 160 m²
Maximum Tx power (2.4 GHz): 23 dBmW
Maximum Tx power (5 GHz): 26 dBmW
Multicast support: Yes
Networking standards: IEEE 802.1Q
Policy-based routing: Yes
VPN server: Identity Endpoint One-Click VPN, Teleport Zero-Configuration VPN, WireGuard, OpenVPN, L2TP
Compatible memory cards: MicroSD (TransFlash)
Ethernet LAN (RJ-45) ports: 4
Fiber optic connector: SFP+
Memory card slot(s): Yes
USB port: No
MIMO: Yes
MU-MIMO technology: Yes
Quality of Service (QoS) support: Yes
Reset button: Yes
Web-based management: Yes
Filtering: Yes
Firewall: Yes
MAC address table: 2000 entries
Security algorithms: PPSK/WPA/WPA2/WPA3/WPA-Enterprise/WPA-PSK
DHCP server: Yes
Routing protocols: OSPF
Built-in display: Yes
Display type: LCM
Housing material: Polycarbonate (PC)
LED indicators: Status
Product colour: White
Product type: Tabletop router
Cables included: AC
Compliance certificates: CE/Federal Communications Commission (FCC)/Industry Canada (IC)
Manual: Yes
Antenna design: Internal
Antenna gain level (max): 7 dBi
Bluetooth: Yes
Built-in processor: Yes
Internal memory: 3000 MB
Number of simultaneously connected devices (max): 300
Processor architecture: ARM Cortex-A53
Processor cores: 4
Processor frequency: 1500 MHz
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 26 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) voltage: 57 V
Power source type: AC,PoE
Power supply: 50 W
Operating relative humidity (H-H): 5 - 95 %
Operating temperature (T-T): -10 - 40 °C
Depth: 110 mm
Height: 184.1 mm
Weight: 1100 g
Width: 110 mm
Number of products included: 1 pc(s)
Model: Dream Router 7
Model name: Dream 7
Units per Shipping Box: 6
Unit Calculated Volume: 0.0122 cubm
Unit Calculated Weight: 1.96 kg
