Tp-Link Switch|TP-LINK|Desktop/pedestal|5x10Base-T / 100Base-TX|PoE ports 4|TL-SF1005P

Write a review

€34.81

Tax included

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Guarantee safe & secure checkout

PoE Switches for Your Ultra Convenience
5-Port 10/100Mbps Desktop Switch with 4-Port PoE

Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

Intelligent Power Management
When total power consumption excels 58W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.

Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

5 10/100Mbps RJ45 ports
With four PoE ports, transfers data and power on one single cable
Working with IEEE 802.3af compliant PDs, expands home and office network
Supports PoE Power up to 15.4W for each PoE port
Supports PoE Power up to 58W for all PoE ports
Requires no configuration and installation

Manufacturer Website:
https://uk.tp-link.com/products/details/cat-42_TL-SF1005P.html

Summary: TP-Link 5-Port 10/100Mbps Desktop PoE Switch with 4-Port. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries, Switching capacity: 1 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE)
Category Code: SWI
CnCode: 85176200
Unit Box Height: 0.12
Unit Box Length: 0.2
Unit Box Width: 0.13
Switch type: Unmanaged
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
10G support: No
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Cable types supported: Cat3/Cat4/Cat5/Cat5e/Cat6
Copper ethernet cabling technology: 100BASE-T/100BASE-TX/10BASE-T
Flow control support: Yes
Full duplex: Yes
Half duplex: Yes
MAC address auto-aging supported: Yes
MAC address auto-learning supported: Yes
Networking standards: IEEE 802.3af/IEEE 802.3x
Forwarding rate: 0.744 Mpps
Jumbo frames: 2000
Jumbo frames support: Yes
MAC address table: 2000 entries
Store-and-forward: Yes
Switching capacity: 1 Gbit/s
LED indicators: Yes
Product colour: Black
Rack mounting: No
Stackable: No
Fanless: Yes
Maximum cable length: 100 m
AC input frequency: 50 Hz
AC input voltage: 220 V
DC input voltage: 53.5 V
Input current: 1.31 A
Power consumption (max): 74 W
Power source: DC/PoE
Power supply included: No
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 4
Total Power over Ethernet (PoE) budget: 67 W
Heat dissipation: 252.34 BTU/h
Operating relative humidity (H-H): 10 - 90 %
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 90 %
Storage temperature (T-T): -40 - 70 °C
Depth: 98 mm
Height: 25 mm
Width: 99.8 mm
User guide: Yes
AC adapter included: Yes
Package depth: 196 mm
Package height: 121 mm
Package type: Box
Package weight: 760 g
Package width: 131 mm
Sustainability compliance: Yes
Compliance certificates: CE/Federal Communications Commission (FCC)/RoHS
Harmonized System (HS) code: 85176990
Units per Shipping Box: 12
Unit Calculated Volume: 0.003844 cubm
Unit Calculated Weight: 0.842 kg

Reference TL-SF1005P

In stock 5 Items

Specific References

EAN13: 6935364083199
MPN: TL-SF1005P

Condition New
