Teltonika Switch|TELTONIKA|TSW110000000|Switch type Unmanaged|Switch layer L2|5xRJ-45 ports|RJ-45 Ports Type Gigabit Ethernet (1

Write a review

€59.06

Tax included

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Guarantee safe & secure checkout

PLUG-N-PLAY

No additional configuration needed

DURABILITY

Rugged aluminium housing

MOUNTING

DIN rail and surface mounting options

STATUS LEDS

1 x Power, 10 x Ethernet

9-30 V

Wide range of supported power supply voltages

GIGABIT ETH

5 x Gigabit Ethernet with speeds up to 1000 Mbps

TSW110 is a layer 2 unmanaged switch, which is a simplified version of our earlier product – TSW100
Possible to power up through the first LAN port
It has five 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution
It offers a wide range of supported power supply voltages (9-30 V)
Ideal for professional high bandwidth applications to provide reliable data connection

Manufacturer Website:
https://teltonika-networks.com/product/tsw110/

Category Code: SWI
CnCode: 85176200
Unit Box Height: 0.07
Unit Box Length: 0.175
Unit Box Width: 0.15
Switch type: Unmanaged
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
10G support: No
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3/IEEE 802.3az/IEEE 802.3u
Jumbo frames: 9216
Jumbo frames support: Yes
MAC address table: 2000 entries
Packet buffer memory: 0.128 MB
Switching capacity: 10 Gbit/s
DIN rail mounting: Yes
Housing material: Aluminium
International Protection (IP) code: IP30
LED indicators: Yes
Product colour: Blue/Grey
AC input voltage: 100 - 240 V
DC input voltage: 30 V
Power consumption (typical): 1.8 W
Power supply included: Yes
Power over Ethernet (PoE): Yes
Operating relative humidity (H-H): 10 - 90 %
Operating temperature (T-T): -40 - 75 °C
Depth: 85 mm
Height: 30 mm
Weight: 227 g
Width: 100 mm
Quick start guide: Yes
Package type: Box
Model: TSW110
Model name: TSW110000000
Units per Shipping Box: 1
Unit Calculated Volume: 0.001837 cubm
Unit Calculated Weight: 0.393 kg

Reference TSW110

In stock 2 Items

Specific References

EAN13: 4779027312958
MPN: TSW110

Condition New
