Mikrotik Access Point|MIKROTIK|3G|4G|5G|5HAXD2HAXD-TC&RG650E-EU

SKU S53UG+5HAXD2HAXD-TC&RG650E-EU Category Access points
Price: €383.71
Tax included
Share on

Chateau 5G ax R17 may look familiar – the sleek design, the mighty dual-band Wi-Fi 6 coverage, and all the impressive RouterOS v7 features. But under the hood, everything’s been pushed further.

Now powered by 5G Release 17 cutting-edge modem, Chateau takes full advantage of the latest mobile technologies, including advanced carrier aggregation combinations. That means faster downlink speeds, increased signal stability and responsiveness, even in regions where the mobile tower is far away. Wherever you are, Chateau finds the signal sweet spot.

Your network, your rules: eSIM or microSIM

Chateau has a true embedded SIM (eSIM) built right in, fully compatible with:
- MikroTik Connectivity (pre-activated data plans)
- Third-party eSIMs (Mobile operator eSIM profiles)
- Multiple eSIM profiles (easily added, switched, or stored)

With four powerful built-in LTE/5G antennas and two external dual-chain Wi-Fi 6 antennas, Chateau gives you great performance for download and upload even in a busy, crowded environment:

- Smart aggregation with wide regional FDD + TDD band support;
- Extra strong signal pickup thanks to 4x4 MIMO;
- Wi-Fi coverage designed for homes of all sizes, including multi-floor setups.

Chateau runs RouterOS v7, MikroTik’s industrial-grade operating system used by ISPs and sysadmins around the world – but with a simple user-friendly interface that anyone can learn to use. And if you’re not sure about diving deep into the world of networking – no worries, we also have iOS/Android app for even easier installation!

Set up a secure VPN. Optimize streaming. Limit bandwidth. Create VLANs. Block sites. Send SMS alerts when usage peaks. All without subscriptions or paywalls.



Manufacturer Website:
https://mikrotik.com/product/chateau_5g_r17_ax#fndtn-specifications

Summary
Mikrotik Chateau 5G R17 ax. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 1200 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Mobile network generation: 5G, 4G standard: LTE-TDD & LTE-FDD, 5G standard: Sub6 NSA, Sub6 SA. Product type: Desktop/pole router, Product colour: Black, Grey, International Protection (IP) code: IP20. Certification: CE, EAC, ROHS
Category Code
WRO
CnCode
85176200
Unit Box Height
0.075
Unit Box Length
0.345
Unit Box Width
0.245
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards
802.11a/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)
574 Mbit/s
WLAN data transfer rate (max)
1200 Mbit/s
WLAN data transfer rate (second band)
1200 Mbit/s
SIM card slot
Yes
Ethernet LAN
Yes
Ethernet LAN data rates
10/100/1000 Mbit/s
Ethernet LAN interface type
Gigabit Ethernet
3G bands supported
2100/850/900 MHz
4G bands supported
1500/1800/2100/2300/2500/2600/3500/3700/700/800/850/900 MHz
4G standard
LTE-TDD & LTE-FDD
5G bands supported
1500/1800/2100/2300/2500/2600/3500/3700/700/800/850/900 MHz
5G standard
Sub6 NSA/Sub6 SA
Mobile network generation
5G
SIM card type
MicroSIM
DC-in jack
Yes
Ethernet LAN (RJ-45) ports
5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
USB port
Yes
Indication light
Yes
International Protection (IP) code
IP20
Product colour
Black/Grey
Product type
Desktop/pole router
Cables included
Power/UTP
Certification
CE, EAC, ROHS
Antenna design
Internal
Built-in processor
Yes
Flash memory
128 MB
Internal memory
1000 MB
Processor cores
4
Power consumption (typical)
27 W
Power source type
DC
Operating temperature (T-T)
-40 - 70 °C
Quantity per pack
1 pc(s)
Units per Shipping Box
5
Unit Calculated Volume
0.00825 cubm
Unit Calculated Weight
1.25 kg
Category Access points Brand MIKROTIK In stock 5 Items
