Mesh-scalable, super-compact 10G Cloud Gateway with integrated WiFi 7.
Manufacturer Website:
https://eu.store.ui.com/eu/en/category/cloud-gateways-wifi-integrated/products/ux7
- Category Code
- GWC
- CnCode
- 85176200
- Unit Box Height
- 0.091
- Unit Box Length
- 0.181
- Unit Box Width
- 0.205
- Enclosure material
- Polycarbonate (PC)
- LED indicators
- Status
- Product colour
- White
- Antenna gain level (max)
- 6 dBi
- Antenna type
- Internal
- Antennas quantity
- 4
- Built-in processor
- Yes
- Control display unit
- Yes
- Display type
- LCM
- Internal memory
- 3000 MB
- Number of processors installed
- 1
- Processor family
- ARM Cortex
- Processor frequency
- 1500 MHz
- Processor manufacturer
- ARM
- Processor model
- Cortex-A53
- DHCP server
- Yes
- Routing protocols
- OSPF
- Bluetooth
- Yes
- Data transfer rate
- 5.7 Gbit/s
- Ethernet LAN data rates
- 10/100/1000/10000/2500 Mbit/s
- Frequency band
- 2.4, 5, 6 GHz
- Load balancing
- Yes
- Networking standards
- IEEE 802.1Q
- Wi-Fi
- Yes
- Wireless connection
- Yes
- WLAN data transfer rates supported
- 1/11/12/18/2/24/300/36/48/5.5/54/6/6.5/9 Mbit/s
- Firewall security
- Yes
- Security algorithms
- 802.1x RADIUS/IPSec/PPSK/TLS/WPA/WPA2/WPA3/WPA-Enterprise/WPA-PSK
- VLAN support
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- WAN connection
- Ethernet (RJ-45)
- Multicast support
- Yes
- Quality of Service (QoS) support
- Yes
- Reset button
- Yes
- Electromagnetic (EMP) protection
- Yes
- Electromagnetic (EMP) protection (air)
- 8 kV
- Electromagnetic (EMP) protection (contact)
- 4 kV
- Input current
- 5 A
- Input voltage
- 100 - 240 V
- Power consumption (max)
- 22 W
- Depth
- 117 mm
- Height
- 42.5 mm
- Weight
- 422 g
- Width
- 117 mm
- AC adapter included
- Yes
- Cables included
- LAN (RJ-45)/Power
- Operating relative humidity (H-H)
- 5 - 95 %
- Operating temperature (T-T)
- -10 - 40 °C
- Compliance certificates
- CE/Federal Communications Commission (FCC)/Industry Canada (IC)
- Display diagonal
- 0.96 "
- Model
- UX7
- Units per Shipping Box
- 10
- Unit Calculated Volume
- 0.007265 cubm
- Product Net Weight
- 0.5 kg
- Unit Calculated Weight
- 1.27 kg
