Dahua LCD Monitor|DAHUA|LM22-L200N|21.45"|Business|1920x1080|16:9|100Hz|5 ms|Speakers|Colour Black|DHI-LM22-L200N
Price:
€78.86
Tax included
Product Comments module (productcomments) must be installed!
Share on
The L200N Series monitor features a top-notch LCD panel that delivers exceptional visuals and a rapid refresh rate. This versatile and dependable display is not only cost-effective but also highly reliable. It seamlessly integrates with a wide range of Dahua backend security devices, making it an ideal choice for both individual desktop setups and wall mount installation in the security industry.
- Suitable for continuous 24/7 operation
- 3 sides narrow bezel design, elegant appearance, ultra-light base
- 5ms fast response time with no image blurring or ghosting
- 178°/178° extra-wide viewing angle for overall viewing performance
- Support multiple signal inputs including HDMI and VGA
- Low energy consumption, long service life
Manufacturer Website:
https://display.dahuasecurity.com/business/en/products/productDetail?product_id=144951
- Category Code
- LC3
- CnCode
- 85285210
- Unit Box Height
- 0.37
- Unit Box Length
- 0.56
- Unit Box Width
- 0.14
- Backlight type
- Edge LED
- Colour depth
- 8 bit
- Colour gamut standard
- NTSC
- Contrast ratio (typical)
- 3000:1
- Display brightness (typical)
- 250 cd/m²
- Display diagonal
- 21.45 "
- Display diagonal (metric)
- 54 cm
- Display resolution
- 1920 x 1080 pixels
- Display technology
- LED
- HD type
- Full HD
- LED backlight
- Yes
- Maximum refresh rate
- 100 Hz
- Native aspect ratio
- 16:9
- NTSC coverage (typical)
- 72 %
- Panel type
- VA
- Response time
- 5 ms
- Screen shape
- Flat
- Touchscreen
- No
- Viewing angle, horizontal
- 178 °
- Viewing angle, vertical
- 178 °
- Operating hours (hours/days)
- 24/7
- Built-in camera
- No
- Built-in speaker(s)
- No
- Detachable stand
- Yes
- Feet colour
- Black
- Frameless design
- Yes
- Front bezel colour
- Black
- Product colour
- Black
- Built-in USB hub
- No
- HDMI
- Yes
- Headphone out
- No
- VGA (D-Sub) ports quantity
- 1
- Height adjustment
- No
- Panel mounting interface
- 100 x 100 mm
- Plug and Play
- Yes
- Tilt adjustment
- Yes
- Tilt angle range
- -5 - 15 °
- VESA mounting
- Yes
- Wall mountable
- Yes
- AC adapter output voltage
- 12 V
- Current rating
- 2 A
- Energy consumption (SDR) per 1000 hours
- 15 kWh
- Energy efficiency class (HDR)
- Not available
- Energy efficiency class (SDR)
- E
- Power consumption (max)
- 21 W
- Power consumption (off)
- 0.3 W
- Power consumption (standby)
- 0.5 W
- Power consumption (typical)
- 20.5 W
- Power supply type
- External
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- 0 - 40 °C
- Storage relative humidity (H-H)
- 5 - 90 %
- Storage temperature (T-T)
- -20 - 60 °C
- Bezel width (bottom)
- 22.1 mm
- Bezel width (side)
- 2 mm
- Bezel width (top)
- 2 mm
- Depth (without stand)
- 48.4 mm
- Height (without stand)
- 290.8 mm
- Weight (without stand)
- 2300 g
- Width (without stand)
- 493.1 mm
- Package depth
- 140 mm
- Package height
- 370 mm
- Package type
- Box
- Package weight
- 3400 g
- Package width
- 557 mm
- Cables included
- HDMI
- Manual
- Yes
- Power adapter included
- Yes
- Quick start guide
- Yes
- Stand included
- Yes
- Compliance certificates
- CE
- Mean time between failures (MTBF)
- 30000 h
- Data Sheet (Link)
- https://eprel.ec.europa.eu/api/product/1977980/fiches?language=EN
- Energy efficiency class
- E
- EPREL Registration Number
- 1977980
- EPREL Version Number
- 1
- Model
- DHI-LM22-L200N
- Model name
- LM22-L200N
- Unit Calculated Volume
- 0.02901 cubm
- Product Net Weight
- 2.3 kg
- Unit Calculated Weight
- 3.5 kg
