Now with airOS®8 and airView®
airOS®8 provides powerful features, including airMAX ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
High-Gain, Directional Antenna
The LiteBeam AC provides 23 dBi of gain for long-distance connectivity and uses a directional antenna pattern for improved noise immunity.
Breakthrough Industrial Design
Featuring the freedom of three-axis alignment, the LiteBeamM fully assembles in seconds – no tools needed. Only a single wrench is required for pole-mounting.
Compact in Size, Light in Weight
A lightweight form factor contained within ultra-compact packaging, the LiteBeam AC is ideal for shipping and logistics.
- Improved Radio Design
- Improved Mounting
- Improved Surge Protection
- Management WiFi Radio/UNMS mobile app
- AirOS 8
Manufacturer Website:
https://ubiquitistore.com.au/product/ubiquiti-litebeam-ac-23dbi-5ghz-802-11ac-antenna-lbe-5ac-gen2-au/
- Category Code
- BRE
- CnCode
- 85176200
- Unit Box Height
- 0.3
- Unit Box Length
- 0.17
- Unit Box Width
- 0.14
- Antenna design
- External
- Antenna gain level (max)
- 23 dBi
- Antennas quantity
- 1
- Frequency band
- 5.15 - 5.875 GHz
- Top Wi-Fi standard
- Wi-Fi 5 (802.11ac)
- Wi-Fi
- Yes
- Wi-Fi band
- Single-band (5 GHz)
- Cabling technology
- 10/100/1000Base-T(X)
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 10/100/1000 Mbit/s
- Ethernet LAN interface type
- Gigabit Ethernet
- Networking standards
- IEEE 802.11ac/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ac/IEEE 802.3u
- Connectivity technology
- Wired & Wireless
- Ethernet LAN (RJ-45) ports
- 1
- Internal memory
- 64 MB
- LED indicators
- LAN/Power
- Material
- Polycarbonate (PC)/SGCC
- Mounting type
- Pole
- Processor family
- Atheros
- Processor manufacturer
- Qualcomm
- Processor model
- MIPS 74Kc
- Product colour
- White
- Product type
- Network bridge
- Rack mounting
- No
- RAM type
- DDR2
- Reset button
- Yes
- Power consumption (max)
- 7 W
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) voltage
- 24 V
- Power source type
- PoE
- Operating relative humidity (H-H)
- 5 - 95 %
- Operating temperature (T-T)
- -40 - 70 °C
- Compliance certificates
- RoHS
- Depth
- 272.5 mm
- Height
- 271.95 mm
- Weight
- 800 g
- Width
- 358 mm
- Sustainability compliance
- Yes
- Model
- UBIQUITI airMAX LiteBeam 5AC Long-Range (LBE-5AC-GEN2)
- Units per Shipping Box
- 8
- Unit Calculated Volume
- 0.007941 cubm
- Unit Calculated Weight
- 1.71 kg
