MSI Motherboard MAG Z890 TOMAHAWK WIFI s1851 4DDR5 ATX
MSI Motherboard MAG Z890 TOMAHAWK WIFI s1851 4DDR5 ATX

MSI Motherboard MAG Z890 TOMAHAWK WIFI s1851 4DDR5 ATX

SKU MAG Z890 TOMAHAWK WIFI Category Mainboards
Price: €384.78
Tax included
Add to Cart
Share on
SKU
KBMSIIIFZ890A01
Barcode
4711377259712
Model
MAG Z890 TOMAHAWK WIFI
CPU socket
LGA1851
Processor family
Intel Core Ultra
Integrated CPU
No
Chipset manufacturer
Intel
Chipset type
 INTEL Z890
Memory type
DDR5
Number of DDR5 slots
4
Memory bus frequency
7200 MHz
Memory bus frequency
9200 MHz
Memory bus frequency
6400 MHz
Memory bus frequency
4800 MHz
Max memory size
256
Expansion slots
4 x M.2
Expansion slots
1 x PCIe 5.0 x 16
Expansion slots
2 x PCIe 4.0 x 4
Max. number of SATA devices
4
RAID
Yes
Detailed data on disk/drive interfaces
M.2_1 Source (From CPU) Supports up to PCIe 5.0 x4, Supports 2280/2260 devices M.2_2 Source (From CPU) Supports up to PCIe 4.0 x4, Supports 22110/2280/2260 devices M.2_3 Source (From Chipset) Supports up to PCIe 4.0 x4, Supports 2280/2260/2242 devices M.2_4 Source (From Chipset) Supports up to PCIe 4.0 x4 / SATA mode, Supports 2280/2260/2242 devices 4x SATA 6G Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Graphics
1x HDMI HDMI 2.1 support with FRL, max resolution 4K 120Hz* 2x Type-C DisplayPort Thunderbolt 4 ports, DisplayPort 2.1 support with UHBR20 over USB Type-C, max resolution 4K@120Hz / 8K@60Hz* *Only available on processors with integrated graphics. Graphics specifications may vary depending on the installed processor.
Network interface
1 x 10/100/1000/2500/5000 Mbit/s
Network interface
Wi-Fi 802.11a/b/g/n/ac/ax/be
Network interface
Bluetooth
Network interface
Intel Killer E5000 5Gbps LAN Intel Killer BE1750x Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4**, MLO, 4KQAM
USB ports at back panel
10
USB ports on motherboard
8
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
7
FireWire (IEEE 1394)
No
COM connector / port
No
LPT connector / port
No
External connectors
1 x S/PDIF
External connectors
1 x USB 3.2 Gen 1 Type-C
External connectors
2 x Thunderbolt 4
External connectors
1 x RJ-45
External connectors
1 x HDMI
External connectors
1 x Line Out
External connectors
1 x MIC
External connectors
4 x USB 3.2 Gen 1 Type-A
External connectors
3 x USB 3.2 Gen 2 Type-A
External connectors
1 x Przycisk Clear CMOS
External connectors
1 x Flash BIOS Button
Onboard connectors
1 x Chassis intrusion header
Onboard connectors
1 x Front panel audio header
Onboard connectors
1 x 4pin CPU fan
Onboard connectors
6 x 4pin wentylator obudowy
Onboard connectors
1 x 4-pin water-pump-fan
Onboard connectors
1 x 8pin 12V power
Onboard connectors
1 x 24pin ATX zasilanie
Onboard connectors
4 x USB 2.0/1.1
Onboard connectors
2 x USB 3.0 header
Onboard connectors
1 x USB C
Onboard connectors
1 x Thunderbolt header
Onboard connectors
1 x TPM header
Onboard connectors
2 x System panel header
Onboard connectors
1 x EZ Conn-header
Onboard connectors
1 x RGB LED strip header
Onboard connectors
3 x Addressable LED
Form factor
ATX
Dimensions
243.84mm x 304.8mm
Supported operating systems
Windows 11
Designation
CE+WEEE
Category Mainboards Brand MSI In stock 5 Items
