Asrock Mainboard|ASROCK|Intel B860|LGA 1851 (Socket V1)|ATX|RAM DDR5-SDRAM|4xSlots|Wi-Fi Yes|Bluetooth Yes|1xNumber of M.2 (M) s

SKU B860 CHALLENGER WIFI WHITE Category Mainboards
Price: €211.49
Tax included
Share on

The Challenger Series motherboard represents fearless play, bold breakthroughs, and relentless evolution, delivering robust specs with Wi-Fi 7 and gamer-centric specs. Featuring an elegant design with comprehensively pure white components, it stands as the visual centerpiece for pristine white gaming builds.

Forge the Future Dominate the Game
Challenger Series is all about fearless play, bold breakthroughs, and relentless evolution. Packed with solid specs at a gamer-friendly price, it’s the ultimate option for gamers.

Forge the Future Dominate the Game
Challenger Series is all about fearless play, bold breakthroughs, and relentless evolution. Packed with solid specs at a gamer-friendly price, it’s the ultimate option for gamers.

DDR5 XMP & EXPO Support
Derived from the “built for stable and reliable” designing concept, ASRock does not compromise on any details. This motherboard is built with high quality materials, enthusiasts are able to enjoy the boost of DDR5 memory overclocking performance by enabling the pre-tested profiles. Make sure the memory modules are Intel® XMP/AMD EXPO™ capable and overclocking can be made so affordable, satisfying and absolutely no sweat at all.

Dragon 2.5 Gb/s LAN
The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you’ll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups.

Front USB 3.2 Gen1 Type-C
Front USB 3.2 Gen1 Type-C header delivers up to 5 Gbps data transfer rate and next generation reversible USB design to the front panel of computer case.

POLYCHROME RGB
This motherboard features onboard RGB headers and addressable RGB headers that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects.



Manufacturer Website:
https://www.asrock.com/MB/Intel/B860%20Challenger%20WiFi%20White/index.asp#Overview

Category Code
MBI
CnCode
84733020
Unit Box Height
0.28
Unit Box Length
0.075
Unit Box Width
0.35
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Component for
PC
Motherboard chipset
Intel B860
Motherboard chipset family
Intel
Motherboard form factor
ATX
Product colour
White
Windows operating systems supported
Windows 11 x64
Compatible processor series
Intel Core Ultra (Series 2)
Processor manufacturer
Intel
Processor socket
LGA 1851 (Socket V1)
Supported processor sockets
LGA 1851
ECC сompatibility
Non-ECC
Maximum internal memory
256 GB
Memory channels
Dual-channel
Memory slots type
DIMM
Number of memory slots
4
Supported memory clock speed (max)
8666 MHz
Supported memory clock speeds
4400/4800/5600/6533/6800/8666 MHz
Supported memory types
DDR5-SDRAM
Unbuffered memory
Yes
Number of HDDs supported
4
Number of storage drives supported
7
RAID levels
0/1/10/5
RAID support
Yes
Supported storage drive interfaces
PCI Express 5.0,M.2,SATA III
Supported storage drive types
HDD & SSD
HDCP
Yes
HDCP version
2.3
High Dynamic Range (HDR) supported
Yes
Parallel processing technology support
Not supported
12V power connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
Front panel audio connector
Yes
Front panel connector
Yes
Number of chassis fan connectors
4
Number of CPU fan connectors
2
Number of EATX power connectors
1
Number of SATA III connectors
4
Number of water pump connectors
1
RGB LED pin header
Yes
TPM connector
Yes
USB 2.0 connectors
8
USB 3.2 Gen 1 (3.1 Gen 1) connectors
9
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
Ethernet LAN (RJ-45) ports
1
HDMI ports quantity
1
HDMI version
2.1
Line-in
Yes
Microphone in
Yes
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
WiFi-AP antenna jack
2
Bluetooth
Yes
Bluetooth version
5.4
Ethernet interface type
2.5 Gigabit Ethernet/Fast Ethernet/Gigabit Ethernet
Ethernet LAN
Yes
LAN controller
Dragon RTL8125BG
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi
Yes
Wi-Fi standards
802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
2280
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
2280
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
2280
Number of M.2 (M) slots
1
PCI Express x16 (Gen 4.x) slots
1
PCI Express x16 (Gen 5.x) slots
1
BIOS flashback button
Yes
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Intel Extreme Memory Profile (XMP)
Yes
Depth
305 mm
Width
244 mm
Antenna included
Yes
Cables included
SATA
M.2 standoff included
Yes
Screws included
Yes
Compliance certificates
CE/Federal Communications Commission (FCC)
Sustainability certificates
ErP
Units per Shipping Box
5
Unit Calculated Volume
0.00959 cubm
Unit Calculated Weight
2.07 kg
Category Mainboards Brand ASROCK In stock 5 Items
