Desktop 10G Cloud Gateway with integrated 4-port 2.5 GbE switch, selectable NVR storage, and full UniFi application support.
Manufacturer Website:
https://eu.store.ui.com/eu/en/category/cloud-gateways-compact/collections/cloud-gateway-fiber/products/ucg-fiber?variant=ucg-fiber-eu
- Category Code
- GWC
- CnCode
- 85176200
- Unit Box Height
- 0.22
- Unit Box Length
- 0.08
- Unit Box Width
- 0.24
- Enclosure material
- Polycarbonate (PC)
- LED indicators
- Status
- Product colour
- White
- Built-in processor
- Yes
- Control display unit
- Yes
- Display type
- LCM
- Internal memory
- 3000 MB
- Number of processors installed
- 1
- Processor family
- ARM Cortex
- Processor frequency
- 2200 MHz
- Processor manufacturer
- ARM
- Routing protocols
- OSPF
- Bluetooth
- Yes
- Ethernet LAN data rates
- 10/100/1000/10000/2500 Mbit/s
- Load balancing
- Yes
- Firewall security
- Yes
- Security algorithms
- 802.1x RADIUS/IPSec/TLS
- VLAN support
- Yes
- DC-in jack
- Yes
- Ethernet LAN (RJ-45) ports
- 4
- SFP+ ports quantity
- 2
- WAN connection
- Ethernet (RJ-45),SFP,SFP+
- Multicast support
- Yes
- Quality of Service (QoS) support
- Yes
- Reset button
- Yes
- DC input voltage
- 54 V
- Electromagnetic (EMP) protection
- Yes
- Electromagnetic (EMP) protection (air)
- 8 kV
- Electromagnetic (EMP) protection (contact)
- 4 kV
- Input current
- 1.1 A
- Input voltage
- 100 - 240 V
- Power consumption (max)
- 29.4 W
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) type supported
- PoE+
- Depth
- 127.6 mm
- Height
- 30 mm
- Weight
- 675 g
- Width
- 212.8 mm
- AC adapter included
- Yes
- Cables included
- LAN (RJ-45)/Power
- Operating relative humidity (H-H)
- 5 - 95 %
- Operating temperature (T-T)
- 0 - 40 °C
- Compliance certificates
- CE/Federal Communications Commission (FCC)/Industry Canada (IC)
- Display diagonal
- 0.96 "
- Export Control Classification Number (ECCN)
- EAR99
- Model
- Cloud Gateway Fiber
- Product model code
- UCG-FIBER
- Units per Shipping Box
- 8
- Unit Calculated Volume
- 0.00816 cubm
- Product Net Weight
- 0.675 kg
- Unit Calculated Weight
- 1.61 kg
