Tp-Link | 5-Port Gigabit Desktop Switch with 4-Port PoE+ | LS105GP | Unmanaged | Desktop

SKU LS105GP Category Switches
Out-of-Stock
Price: €26.52
Tax included
Out-of-Stock
Share on

Overview
The TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

  • Full Gigabit Ports: Five gigabit augo-negotiation ports provide up to 10 Gbps switching capacity
  • 65 W PoE Budget: Four gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
  • Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
  • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
  • Plug and Play: Simply plug and play for instant connectivity with no configuration required
  • Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses
  • Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments



Manufacturer Website:
https://www.tp-link.com/uk/business-networking/soho-switch-poe/ls105gp/#specifications

Summary
TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE)
Category Code
SWI
CnCode
85176200
Unit Box Height
0.12
Unit Box Length
0.2
Unit Box Width
0.13
Quality of Service (QoS) support
Yes
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
10G support
No
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
Cable types supported
Cat3/Cat4/Cat5/Cat5e
Flow control support
Yes
MAC address auto-aging supported
Yes
MAC address auto-learning supported
Yes
Networking standards
IEEE 802.1p/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x
Forwarding rate
7.44 Mpps
Jumbo frames
16000
MAC address table
2000 entries
Store-and-forward
Yes
Switching capacity
10 Gbit/s
IGMP snooping
Yes
LED indicators
Yes
Product colour
Black
AC input frequency
50 Hz
AC input voltage
220 V
DC input voltage
53.5 V
Power consumption (max)
74.46 W
Power source
DC/PoE
Power supply included
Yes
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
4
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
65 W
Heat dissipation
253.16 BTU/h
Operating relative humidity (H-H)
10 - 90 %
Operating temperature (T-T)
0 - 40 °C
Storage relative humidity (H-H)
5 - 90 %
Storage temperature (T-T)
-40 - 70 °C
Depth
98 mm
Height
25 mm
Width
99.8 mm
User guide
Yes
Package type
Box
Certification
CE, FCC, RoHS
Model
TP-LINK LS105GP
Model name
LS105GP
Units per Shipping Box
12
Unit Calculated Volume
0.003959 cubm
Unit Calculated Weight
0.767 kg
Category Switches Brand TP-LINK EAN13 4895252504545
