SKU TL-SG116P Category Switche
Out-of-Stock
Price: €118.65
Tax included
Out-of-Stock
Add to Cart
Share on

NET SWITCH 16PORT 1000M POE+/TL-SG116P TP-LINK

  • With 16 PoE+ ports, transfers data and power on one single cable
  • Compliance with IEEE 802.3af/at PoE+, the switch supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 120 W for all PoE ports*
  • Up to 250 m data and power transmission range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–4 to guarantee the quality of the sensitive applications
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery
  • Plug and play with no configuration required



Manufacturer Website:
https://www.tp-link.com/au/business-networking/unmanaged-switch/tl-sg116p/

Category Code
SWI
CnCode
85176200
Unit Box Height
0.23
Unit Box Length
0.435
Unit Box Width
0.07
Quality of Service (QoS) support
Yes
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
16
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
Broadcast storm control
Yes
Cable length detection
Yes
Cable types supported
Cat3/Cat4/Cat5/Cat5e/Cat6
Copper ethernet cabling technology
1000BASE-T/100BASE-TX/10BASE-T
Flow control support
Yes
Full duplex
Yes
Link aggregation
Yes
Networking standards
IEEE 802.1p/IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u
Number of VLANs
32
Port mirroring
Yes
Rate limiting
Yes
Virtual LAN features
Protocol-based VLAN/Tagged VLAN
VLAN support
Yes
Forwarding rate
23.81 Mpps
Jumbo frames
9000
Jumbo frames support
Yes
MAC address table
8000 entries
Number of queues
4
Packet buffer memory
4.1 MB
Store-and-forward
Yes
Switching capacity
32 Gbit/s
IGMP snooping
Yes
Loop protection
Yes
Housing material
Metal
LED indicators
Yes
Product colour
Black
Stackable
Yes
Wall mountable
Yes
AC input frequency
50 Hz
AC input voltage
220 V
DC input voltage
9 V
Input current
0.6 A
Power consumption (max)
144.28 W
Power consumption (typical)
11.72 W
Power supply included
Yes
Power over Ethernet (PoE)
Yes
Heat dissipation
490.55 BTU/h
Operating relative humidity (H-H)
10 - 90 %
Operating temperature (T-T)
0 - 40 °C
Storage relative humidity (H-H)
5 - 90 %
Storage temperature (T-T)
-40 - 70 °C
Depth
111.7 mm
Height
25.4 mm
Width
286 mm
Quick start guide
Yes
Package depth
434 mm
Package height
70 mm
Package weight
2000 g
Package width
227 mm
Model
TL-SG116P
Units per Shipping Box
6
Unit Calculated Volume
0.008645 cubm
Unit Calculated Weight
2.27 kg
Category Switche Brand TP-LINK EAN13 4895252500301
