TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
- 24× Gigabit 802.3af/at PoE+ ports and 4× Gigabit SFP slots
- 250 W total PoE budget with up to 30 W PoE output per port*
- Centralized cloud management via the web or the Omada app†
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, and IGMP Snooping
- Durable metal casing and rackmountable design
Manufacturer Website:
https://www.tp-link.com/en/business-networking/omada-switch-poe/sg2428p/#overview
- Category Code
- SWI
- CnCode
- 85176200
- Unit Box Height
- 0.105
- Unit Box Length
- 0.53
- Unit Box Width
- 0.335
- ARP inspection
- Yes
- MIB support
- Y
- Quality of Service (QoS) support
- Yes
- Switch layer
- L2/L2+
- Switch type
- Managed
- System event log
- Yes
- Web-based management
- Yes
- Basic switching RJ-45 Ethernet ports quantity
- 24
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity
- 24
- SFP module slots quantity
- 4
- 10G support
- No
- Broadcast storm control
- Yes
- Cable types supported
- Cat3/Cat4/Cat5/Cat5e
- Copper ethernet cabling technology
- 1000BASE-T/10BASE-T
- Flow control support
- Yes
- Link aggregation
- Yes
- Networking standards
- IEEE 802.1D/IEEE 802.1p/IEEE 802.1Q/IEEE 802.1s/IEEE 802.1w/IEEE 802.1x/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
- Number of VLANs
- 4000
- Port mirroring
- Yes
- Rate limiting
- Yes
- Spanning tree protocol
- Yes
- Virtual LAN features
- MAC address-based VLAN/Protocol-based VLAN/Voice VLAN
- VLAN support
- Yes
- Fiber ethernet cabling technology
- 1000BASE-X
- Forwarding rate
- 41.66 Mpps
- Jumbo frames
- 9000
- Jumbo frames support
- Yes
- MAC address table
- 8000 entries
- Number of queues
- 8
- Packet buffer memory
- 4.1 MB
- Switching capacity
- 56 Gbit/s
- Access Control List (ACL)
- Yes
- Authentication type
- RADIUS
- BPDU filtering/protection
- Yes
- DHCP features
- DHCP client/DHCP relay/DHCP server/DHCP snooping/DHCPv6 client
- IGMP snooping
- Yes
- IP-MAC-Port binding
- Yes
- Queue scheduling algorithms
- SP/Weighted Round Robin (WRR)/WRR+SP
- Security algorithms
- HTTPS/SNMP/SNMPv2/SNMPv3/SSH/SSH-2/SSL/TLS
- SSH/SSL support
- Yes
- Multicast support
- Yes
- Management protocols
- SNMPv1/v2c/v3, SNTP
- Form factor
- 1U
- Number of fans
- 2 fan(s)
- Product colour
- Black
- Rack mounting
- Yes
- Firmware upgradeable
- Yes
- AC input frequency
- 50/60 Hz
- AC input voltage
- 100 - 240 V
- Power consumption (max)
- 301.1 W
- Power source
- AC
- Power supply included
- Yes
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) power per port
- 30 W
- Power over Ethernet plus (PoE+) ports quantity
- 24
- Total Power over Ethernet (PoE) budget
- 250 W
- Heat dissipation
- 1052.94 BTU/h
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- 0 - 50 °C
- Storage relative humidity (H-H)
- 5 - 90 %
- Storage temperature (T-T)
- -40 - 70 °C
- Depth
- 220 mm
- Height
- 44 mm
- Width
- 440 mm
- Cables included
- AC
- Rack mount kit
- Yes
- User guide
- Yes
- Certification
- CE, FCC, RoHS
- Product Net Weight
- 3.98 kg
- Shipping Box Depth
- 55 cm
- Shipping Box Height
- 42.5 cm
- Shipping Box Weight
- 16.9 kg
- Shipping Box Width
- 36 cm
- Unit Calculated Volume
- 0.02104 cubm
- Unit Calculated Weight
- 4.22 kg
- Units per Shipping Box
- 4
- Series
- Omada
- Model name
- Omada 28-Port Gigabit Smart Switch with 24-Port PoE+
