Dahua Wireless series cameras are not only easy to install and operate, but also perform outstandingly and cost-effective. They provide full coverage of a scene with 5MP resolution, 0° to 355° pan and -5°to 80° tilt. Their powerful functions, such as preset petrol, AI human detection & pet detection, and auto tracking, assist with the accurate detection and continuous tracking of targets. Information is also synchronously sent to your phone to keep you up-to-date. These cameras are widely used in small and medium-sized scenes such as small-sized retail stores.
Manufacturer Website:
https://www.dahuasecurity.com/es/products/All-Products/Network-Cameras/Wireless-Series/Indoor-Camera/Hero-Series/H5A
- Summary
- Dahua Technology H5A. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired & Wireless. Mounting type: Desk, Product colour: Black, White, Form factor: Dome. Lens viewing angle, horizontal: 74°, Lens viewing angle, vertical: 41°, Lens viewing angle, diagonal: 88°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Night vision distance: 10 m, LED type: IR
- Category Code
- NCI
- CnCode
- 85258900
- Unit Box Height
- 0.183
- Unit Box Length
- 0.1
- Unit Box Width
- 0.09
- Auto-tracking
- Yes
- Certification
- CE
- Connectivity technology
- Wired & Wireless
- Day/night mode
- Yes
- Placement supported
- Indoor
- Type
- IP security camera
- Wide Dynamic Range (WDR)
- Yes
- Form factor
- Dome
- Housing material
- Plastic
- Mounting type
- Desk
- Product colour
- Black/White
- Camera shutter speed
- 1/3 - 1/100000 s
- Camera shutter type
- Electronic
- Lens viewing angle, diagonal
- 88 °
- Lens viewing angle, horizontal
- 74 °
- Lens viewing angle, vertical
- 41 °
- Pan range
- 0 - 355 °
- Tilt angle range
- -5 - 80 °
- Optical sensor size
- 1/3 "
- Sensor type
- CMOS
- Maximum aperture number
- 2
- LED type
- IR
- Night vision
- Yes
- Night vision distance
- 10 m
- Number of illumination LEDs
- 1
- Bit rate
- 80 kbps - 4096 kbps
- Digital Wide Dynamic Range (DWDR)
- Yes
- Frame rate
- 30 fps
- Maximum resolution
- 2880 x 1620 pixels
- Total megapixels
- 5 MP
- Video formats supported
- H.265
- Video streaming
- Yes
- Built-in microphone
- Yes
- Built-in speaker(s)
- Yes
- Voice codecs
- G.711a
- Bluetooth
- Yes
- Ethernet LAN
- Yes
- Wi-Fi
- Yes
- Wi-Fi standards
- Wi-Fi 6 (802.11ax)
- Built-in HDD
- No
- Card reader integrated
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 256 GB
- Ethernet LAN (RJ-45) ports
- 1
- Motion sensor
- Yes
- DC output voltage
- 5
- Power consumption (max)
- 4 W
- Power consumption (typical)
- 1.9 W
- Power source type
- DC
- Operating relative humidity (H-H)
- 0 - 95 %
- Operating temperature (T-T)
- -10 - 45 °C
- Depth
- 77.8 mm
- Height
- 108.1 mm
- Weight
- 195 g
- Width
- 77.8 mm
- Model
- H5A
- Units per Shipping Box
- 30
- Unit Calculated Volume
- 0.001955 cubm
- Unit Calculated Weight
- 0.403 kg
