SKU PRO Z890-S WIFI6E Category Mainboards
New
Price: €241.88
Tax included
Add to Cart
Share on
SKU
KBMSIIIFZ890A11
Barcode
4711377427425
Model
PRO Z890-S WIFI6E
CPU socket
LGA1851
Processor family
Intel Core Ultra
Processor Series
Series 2
Integrated CPU
No
Chipset manufacturer
Intel
Chipset type
INTEL Z890
Memory type
DDR5
Number of DDR5 slots
4
Memory bus frequency
4800 MHz
Memory bus frequency
8800 MHz
Max memory size
256
Expansion slots
1 x PCIe 3.0 x 1
Expansion slots
2 x PCIe 4.0 x 4
Expansion slots
1 x PCIe 5.0 x 16
Max. number of SATA devices
3
RAID
Yes
Detailed data on disk/drive interfaces
3 x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4 x SATA 6G
Graphics
1 x HDMI - Support HDMI(TM) 2.1, maximum resolution of 4K 60Hz 1 x DisplayPort - Support DisplayPort 1.4, maximum resolution of 4K 60Hz
Sound card
Realtek(R) ALC897 Codec 7.1-Channel High Definition Audio
Network interface
1 x 10/100/1000/2500 Mbit/s
Network interface
Bluetooth
Network interface
Wi-Fi 802.11a/b/g/n/ac/ax
Network interface
LAN: Realtek(R) 8125D 2.5Gbps LAN WIRELESS LAN & BLUETOOTH: Wi-Fi 6E module The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth(R) 5.3, FIPS, FISMA
USB ports at back panel
7
USB ports on motherboard
7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
8
FireWire (IEEE 1394)
No
COM connector / port
No
LPT connector / port
No
External connectors
1 x Line Out
External connectors
1 x RJ-45
External connectors
6 x USB 3.2 Gen 1 Type-A
External connectors
1 x DisplayPort
External connectors
2 x SMA
External connectors
1 x Line In
External connectors
1 x HDMI
External connectors
1 x MIC
External connectors
1 x USB 3.2 Gen 2x2 Type-C
Onboard connectors
1 x 4pin CPU fan
Onboard connectors
1 x TPM header
Onboard connectors
1 x USB 3.2 Gen 2x2 Type-C
Onboard connectors
4 x SATA III 6Gb/s
Onboard connectors
1 x Chassis intrusion header
Onboard connectors
1 x RGB LED strip header
Onboard connectors
3 x Addressable LED
Onboard connectors
4 x USB 2.0/1.1
Onboard connectors
2 x System panel header
Onboard connectors
1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors
2 x 8pin 12V
Onboard connectors
3 x M.2
Onboard connectors
4 x 4pin Chassis fan
Onboard connectors
2 x USB 3.2 Gen 1 Type-A
Onboard connectors
4 x EZ Debug LED
Onboard connectors
1 x Tuning Controller connector
Onboard connectors
1 x 8-pin PCIe
Onboard connectors
1 x Front panel audio header
Onboard connectors
1 x 24pin ATX zasilanie
Form factor
ATX
Dimensions
243.84 x 304.8 mm
Supported operating systems
Windows 11
Designation
CE+WEEE
Data Act
Link
Category Mainboards Brand MSI EAN13 4711377427425 In stock 10 Items
