Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
- Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format
- 32-channel 1080p self-adaptive decoding capability
- Max. 384 Mbps incoming/recording/outgoing bandwidth
- AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
- AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people
- counting
- Security baseline 2.3
Manufacturer Website:
https://www.dahuasecurity.com/
- Category Code
- NVR
- CnCode
- 85219000
- Unit Box Height
- 0.21
- Unit Box Length
- 0.525
- Unit Box Width
- 0.495
- Alarm input channels
- 16
- Alarm output channels
- 6
- Audio formats supported
- G.711 A-law/G.726/PCM
- Face detection
- Yes
- Maximum resolution
- 1920 x 1080 pixels
- Multi-screen
- Yes
- Number of fans
- 1 fan(s)
- Operating system installed
- Embedded LINUX
- Video formats supported
- H.264/H.264+/H.265/H.265+
- Video input channels
- 32 channels
- Video motion detection
- Yes
- Wi-Fi
- No
- HDD capacity
- 0 GB
- HDD interface
- SATA III
- Maximum storage capacity
- 16 TB
- Number of HDDs supported
- 4
- Audio RCA inputs
- 1
- Audio RCA outputs
- 1
- DVI ports quantity
- 2
- eSATA
- Yes
- eSATA ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 2
- Ethernet LAN data rates
- 10/100/1000 Mbit/s
- HDMI ports quantity
- 2
- RS-232 interface
- Yes
- RS-485 ports
- 1
- Supported network protocols
- HTTP; HTTPS; TCP/IP; IPv4/IPv6; RTSP; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration
- USB 2.0 ports quantity
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- VGA (D-Sub) output ports
- 2
- Certification
- FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021;EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 CE-LVD: EN 62368-1: 2014
- Product colour
- Black
- Rack capacity
- 1.5U
- Rack mounting
- Yes
- Built-in processor
- Yes
- AC input frequency
- 50 - 60 Hz
- AC input voltage
- 100 - 240 V
- Power consumption (typical)
- 13 W
- Operating relative humidity (H-H)
- 10 - 93 %
- Operating temperature (T-T)
- -10 - 55 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Depth
- 415.1 mm
- Height
- 70 mm
- Package depth
- 500 mm
- Package height
- 210 mm
- Package weight
- 6110 g
- Package width
- 530 mm
- Weight
- 4740 g
- Width
- 440 mm
- Product Net Weight
- 4.74 kg
- Shipping Box Depth
- 55 cm
- Shipping Box Height
- 46 cm
- Shipping Box Weight
- 14.3999996185303 kg
- Shipping Box Width
- 52 cm
- Unit Calculated Volume
- 0.06578 cubm
- Unit Calculated Weight
- 7.2 kg
- Units per Shipping Box
- 2
- Model name
- DHI-NVR5432-EI
