Dahua NET CAMERA 8MP EYEBALL/HDW3849H-AS-PV-0360BS5B DAHUA
Price:
€347.61
Tax included
Share on
The parameters and datasheets below can only be applied to 3849-PV-S5 series.
- 8-MP 1/2.7" CMOS image sensor, low luminance, and high definition image
- Outputs max. 8 MP (3840 ×2160)@25/30 fps
- H.265 codec, high compression rate, ultra-low bit rate
- Built-in warm light and IR LED; the max. IR illumination distance is 30 m and warm light distance is 30 m
- ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), stay detection, loitering detection; face detection (full image)
- Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; buit-in dual Mic; 1-ch speaker; support two-way talk
- 12 VDC/PoE power supply
- IP67 protection. · Sound and light alarm (red and blue lights)
- SMD 4.0
- Supports AI SSA and one-tap arming and disarming
- SMD area can be set in warm light areas that support triggering alarms
Manufacturer Website:
https://www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-3-Series/TiOC/IPC-HDW3849H-AS-PV=S5
- Category Code
- FNC
- CnCode
- 85258900
- Unit Box Height
- 0.14
- Unit Box Length
- 0.16
- Unit Box Width
- 0.16
- Form factor
- Turret
- Housing material
- Metal
- International Protection (IP) code
- IP67
- Mounting type
- Ceiling/wall
- Product colour
- Black
- Alarm input/output
- Yes
- Connectivity technology
- Wired
- Day/night mode
- Yes
- Placement supported
- Indoor & outdoor
- Type
- IP security camera
- Wide Dynamic Range (WDR)
- Yes
- Angle of rotation
- 360 °
- Camera shutter speed
- 1/3 - 1/100000 s
- Lens viewing angle, diagonal
- 125 °
- Lens viewing angle, horizontal
- 106 °
- Lens viewing angle, vertical
- 55 °
- Minimum illumination
- 0.0004 lx
- Number of Privacy masking areas
- 4
- Pan range
- 0 - 360 °
- Tilt angle range
- 0 - 78 °
- White balance
- Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
- Number of sensors
- 1
- Optical sensor size
- 1/2.7 "
- Progressive scan
- Yes
- Sensor type
- CMOS
- Closest focusing distance
- 1.5 m
- Detect distance
- 66 m
- Fixed focus
- Yes
- Identify distance
- 6.6 m
- Maximum aperture number
- 1
- Number of lenses
- 1
- Observe distance
- 26.4 m
- Recognize distance
- 13.2 m
- LED type
- IR/White
- Night vision
- Yes
- Night vision distance
- 30 m
- Number of illumination LEDs
- 2
- Back Light Compensation (BLC)
- Yes
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Frame rate
- 30 fps
- Gain control type
- Auto
- Highlight Compensation (HLC)
- Yes
- Maximum resolution
- 3840 x 2160 pixels
- Noise reduction
- Yes
- Noise reduction technology
- 3D noise reduction
- Region of Interest (ROI) encoding
- Yes
- Supported graphics resolutions
- 1280 x 720 (HD 720)/1280 x 960/1536 x 2048/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2592 x 1944/2688 x 1520/3072 x 1728/3072 x 2048/352 x 240/352 x 288/3840 x 2160/640 x 480 (VGA)/704 x 480/704 x 576
- Total megapixels
- 8 MP
- Video compression formats
- H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG
- Video streaming
- Yes
- Audio formats supported
- G.723/G.726
- Audio input channels
- 1.0 channels
- Audio output channels
- 1.0 channels
- Built-in microphone
- Yes
- Built-in speaker(s)
- Yes
- Signal-to-Noise Ratio (SNR)
- 56 dB
- Bluetooth
- No
- Ethernet LAN
- Yes
- Number of users
- 20 user(s)
- Streaming method
- Multicast
- Supported network protocols
- IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P
- Wi-Fi
- No
- Built-in HDD
- No
- Card reader integrated
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 256 GB
- RAM capacity
- 2000 MB
- ROM capacity
- 256 MB
- Alarm input channels
- 1
- Alarm output channels
- 1
- Digital watermark
- Yes
- Intelligent Video Surveillance (IVS) system features
- Intrusion/Tripwire
- Mirror
- Yes
- Security algorithms
- HTTPS
- Video motion detection
- Yes
- Management software
- Smart PSS Lite; DSS; DMSS
- DC output voltage
- 12
- Power consumption (max)
- 8.6 W
- Power consumption (Power over Ethernet (PoE))
- 5.8 W
- Power consumption (typical)
- 4.5 W
- Power source type
- DC,PoE
- Operating relative humidity (H-H)
- 0 - 95 %
- Operating temperature (T-T)
- -40 - 60 °C
- Storage temperature (T-T)
- -40 - 60 °C
- Mobile operating systems supported
- Android/iOS
- Diameter
- 122 mm
- Height
- 110.9 mm
- Weight
- 750 g
- Compliance certificates
- CE/Electromagnetic Compatibility (EMC)
- Package type
- Box
- Package weight
- 920 g
- Manual
- Yes
- Number of cameras
- 1
- Browser supported
- IE: IE 9/11, Chrome, Firefox
- Lens mount interface
- M12
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.003584 cubm
- Unit Calculated Weight
- 0.92 kg
