Eaton UPS 5P 650VA G2 Rack 1U 1p line-in
Price:
€645.49
Tax included
Product Comments module (productcomments) must be installed!
Last items in stock
Share on
UPS topology Line-Interactive
Output power capacity 0.65 kVA
Output power 520 W
Waveform Pure sine
Input operation voltage (min) 160 V
Input operation voltage (max) 294 V
Input frequency 40/70 Hz
Output frequency 50/60 Hz
Number of input phases 1
Number of output phases 1
Efficiency 98 %
AC outlet types C13 coupler
Power plug C14 coupler
USB port Yes
Battery technology Sealed Lead Acid (VRLA)
Form factor Rackmount
Colour Black
Display type LCD
Operating temperature (T-T) 0 - 35 °C
Rack mount kit Yes
Weight 8.6 kg
Manufacturer Website:
https://www.eaton.com/gb/en-gb/skuPage.5P650IRG2.html
- Category Code
- UPW
- CnCode
- 85044095
- Unit Box Height
- 0.175
- Unit Box Length
- 0.59
- Unit Box Width
- 0.445
- ECO mode
- No
- Efficiency
- 98 %
- Input frequency
- 40/70 Hz
- Input operation voltage (max)
- 294 V
- Input operation voltage (min)
- 160 V
- Noise level
- 40 dB
- Number of input phases
- 1
- Number of output phases
- 1
- Output frequency
- 50/60 Hz
- Output operation voltage (max)
- 240 V
- Output operation voltage (min)
- 200 V
- Output power
- 520 W
- Output power capacity
- 0.65 kVA
- UPS topology
- Line-Interactive
- Waveform
- Pure sine
- AC outlet types
- C13 coupler
- AC outlets quantity
- 4 AC outlet(s)
- Power plug
- C14 coupler
- RS-232 ports
- 1
- USB 2.0 ports quantity
- 1
- USB port
- Yes
- Automatic battery test
- Yes
- Battery technology
- Sealed Lead Acid (VRLA)
- Hot-swap battery
- Yes
- Typical backup time at full load
- 2 min
- Typical backup time at half load
- 9 min
- Display type
- LCD
- Form factor
- Rackmount
- Product colour
- Black
- Rack capacity
- 1U
- Operating temperature (T-T)
- 0 - 35 °C
- Certification
- IEC/EN 62040-1, UL 1778, IEC/EN 62040 -2 , IEC/EN 62040-3 (Performance), CE, CB report (TUV)
- Management card included
- No
- Rack mount kit
- Yes
- Safety
- IEC/EN 62040-1, UL 1778
- Depth
- 361 mm
- Height
- 43.2 mm
- Weight
- 8600 g
- Width
- 438 mm
- Bundled software
- Intelligent Power Software suite
- Input connection type
- IEC C14
- Mac compatibility
- No
- Nominal input voltage
- 230 V
- Nominal output voltage
- 230 V
- Model
- 5P Gen2
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.04595 cubm
- Unit Calculated Weight
- 11.2 kg
