Ubiquiti UXG-Lite-EU Gateway UniFi
€134.33
- SKU
- NUTPLSZ5P20GP11
- Barcode
- 1210002609746
- Switch class
- Managed
- Application
- Medium and large companies
- Switch layer
- L2
- Network architecture
- GigabitEthernet
- Number of 10/100/1000 Mbps ports
- 20
- Number of PoE+ ports
- 16
- Number of SFP ports
- 2
- Console port
- No
- Forwarding mode
- Store-and-forward
- Throughput
- 40
- Forwarding rate
- 29.76
- Packet buffer
- 4
- MAC address table size
- 8000
- Support for Jumbo frames
- Yes
- Jumbo frame size
- 15
- Stackability
- No
- Number of VLAN groups
- 32
- VLAN
- MTU VLAN Port-Based VLAN 802.1Q Tag VLAN Max 32 VLAN Groups 4K VID
- QoS
- Port-based/802.1p/DSCP QoS 8 Priority Queues Priority Schedule Mode WRR (Weighted Round Robin) Queue Weight Config Bandwidth Control Port-Based Rating Limit Storm Control Multiple Control Modes (kbps/pps) Broadcast/Multicast/Unknown-Unicast Control
- Management, monitoring, configuration
- Omada App: Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Cloud Access: Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Zero-Touch Provisioning: Requires the use of Omada Cloud-Based Controller. Centralized Management: Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller Management Features: Web-based GUI DHCP Client Cable Diagnostics Automatic Device Discovery Batch Configuration Batch Firmware Upgrading Unified Configuration
- L2 features
- Static Link Aggregation Loop Prevention / Loopback Detection 802.3x Flow Control Mirroring Port Mirroring One-to-One Many-to-One Ingress/Egress/Both Port Statistics Port Mirror Status Traffic Statistics 802.1ab LLDP L2 Multicast: IGMP Snooping IGMP v1/v2/v3 Snooping Fast Leave
- Chassis type
- Rack
- Chassis type
- Desktop
- Fan
- No
- Power supply
- Internal
- Power consumption
- 150
- Environment requirements
- Operating Temperature: -5~40°C Storage Temperature: -40~70°C Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
- Certificates
- FCC CE RoHS
- Accessories included
- ES220GP Power Cord Mounting Brackets Rubber Feet Screws Installation Guide
- Power supply
- 100-240V AC, 50/60Hz 2,5A
- Dimensions
- 294 x 180 x 44 mm
- Designation
- CE+WEEE
- Data Act
- Link
