Gigabyte Motherboard Z890 AORUS ELITE DUO X S1851 4DDR5 ATX

Gigabyte Motherboard Z890 AORUS ELITE DUO X S1851 4DDR5 ATX

Name: Gigabyte Motherboard Z890 AORUS ELITE DUO X S1851 4DDR5 ATX
Brand: GIGABYTE
SKU: Z890 A ELT DUO X
Price: 329.01 EUR
Availability: InStock

SKU Z890 A ELT DUO X Category Mainboards

New

€329.01

Tax included

Last items in stock

Share on

SKU: KBGBAIIFZ890A14
Barcode: 4719331880408
Model: Z890 AORUS ELITE DUO X
CPU socket: LGA1851
Processor family: Intel Core Ultra
Integrated CPU: No
Chipset manufacturer: Intel
Chipset type: Intel Z890 Express
Memory type: DDR5
Number of DDR5 slots: 2
Memory bus frequency: 10266 MHz
Max memory size: 256
Expansion slots: 2 x PCIe 4.0 x 16
Expansion slots: 1 x PCIe 5.0 x 16
Max. number of SATA devices: 4
RAID: Yes
Detailed data on disk/drive interfaces: CPU: 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0x4/x2 SSD support) (M2A_CPU) 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) (M2L_SB) 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0x4/x2 SSD support) (M2M_SB) 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devicesRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Graphics: Integrated Graphics Processor-Intel(R) HD Graphics support: 1 x USB4 USB Type-C port, supporting USB4 and DisplayPort video outputs and a maximum resolution of 4096x2304@144 Hz - Support for DisplayPort 2.1 version and HDCP 2.3 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz - Support for DisplayPort 2.1 version and HDCP 2.3
Sound card: Realtek(R) ALC1220 CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Network interface: Wi-Fi 802.11a/b/g/n/ac/ax/be
Network interface: Bluetooth
Network interface: 1 x 10/100/1000/2500/5000 Mbit/s
Network interface: LAN: Realtek(R) 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)Wireless Communication module Intel(R) Wi-Fi 7 BE200NGW 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.4 Support for 11be 320MHz wireless standard
USB ports at back panel: 11
USB ports on motherboard: 7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports: 5
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports: 3
FireWire (IEEE 1394): No
COM connector / port: No
LPT connector / port: No
External connectors: 1 x RJ-45
External connectors: 1 x Line Out
External connectors: 2 x SMA
External connectors: 1 x DisplayPort
External connectors: 4 x USB 2.0
External connectors: 1 x S/PDIF
External connectors: 1 x Q-Flash Plus button
External connectors: 2 x USB 3.2 Gen 2 Type-A
External connectors: 3 x USB 3.2 Gen 1 Type-A
External connectors: 1 x Przycisk Clear CMOS
External connectors: 1 x USB4 Type-C
External connectors: Power button
External connectors: Reset button
External connectors: 1 x MIC
Onboard connectors: 1 x Clear CMOS jumper
Onboard connectors: 1 x TPM header
Onboard connectors: 1 x RGB LED strip header
Onboard connectors: 1 x Reset jumper
Onboard connectors: 1 x USB 3.2 Gen 2x2 Type-C
Onboard connectors: 1 x 4-pin water-pump-fan
Onboard connectors: 5 x M.2
Onboard connectors: 1 x 4pin CPU fan
Onboard connectors: 4 x SATA III 6Gb/s
Onboard connectors: 2 x Thunderbolt
Onboard connectors: 2 x USB 3.2 Gen 1 Type-A
Onboard connectors: 1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors: 4 x USB 2.0/1.1
Onboard connectors: 1 x System panel header
Onboard connectors: 3 x 4pin Chassis fan
Onboard connectors: 2 x 8pin 12V
Onboard connectors: 3 x Addressable LED
Onboard connectors: 1 x 24pin ATX zasilanie
Onboard connectors: 1 x Front panel audio header
BIOS: 1 x 512 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form factor: ATX
Dimensions: 30.5 x 24.4 cm
Supported operating systems: Windows 11
Software: Norton Internet Security (OEM version)
Designation: CE+WEEE
