Teltonika Switch|TELTONIKA|TSW101000000|PoE ports 4|60 Watts|TSW101
Price:
€86.10
Tax included
Product Comments module (productcomments) must be installed!
Share on
AUTOMOTIVE POE+ SWITCH
Our first-ever switch for the automotive industry features five Gigabit Ethernet ports with PoE+ support to connect multiple devices to the network and power them up using the same interfaces. Enjoy reliable high bandwidth connectivity in a simple, economical, and easy-to-install solution.
Manufacturer Website:
https://teltonika-networks.com/products/switches/tsw101
- Category Code
- SWI
- CnCode
- 85176200
- Unit Box Height
- 0.15
- Unit Box Length
- 0.17
- Unit Box Width
- 0.035
- Basic switching RJ-45 Ethernet ports quantity
- 5
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Power connector
- Terminal block (2-pin)
- 10G support
- No
- Auto MDI/MDI-X
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Networking standards
- IEEE 802.3/IEEE 802.3az/IEEE 802.3u
- Jumbo frames
- 9216
- Jumbo frames support
- Yes
- MAC address table
- 2000 entries
- Switching capacity
- 10 Gbit/s
- Housing material
- Aluminium
- International Protection (IP) code
- IP30
- LED indicators
- Power/Status
- Product colour
- Metallic
- Input voltage
- 9 - 30 V
- Power consumption (max)
- 2.31 W
- Power consumption (typical)
- 0.64 W
- Power source
- DC
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) ports quantity
- 4
- Power over Ethernet (PoE) power per port
- 30 W
- Power over Ethernet (PoE) type supported
- Passive PoE
- Total Power over Ethernet (PoE) budget
- 120 W
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- -40 - 75 °C
- Depth
- 32 mm
- Height
- 95 mm
- Weight
- 354 g
- Width
- 115 mm
- Certification
- CE, REACH, RoHS, WEEE TSW101 CE TSW101 UKCA TSW101 FCC TSW101 IC TSW101 CB TSW101 RCM E-Mark
- Harmonized System (HS) code
- 851762
- Model
- TSW101
- Model name
- TSW101000000
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.0008925 cubm
- Unit Calculated Weight
- 0.44 kg
