SKU DH-CS4010-8GT-110 Category Switche
Price: €102.93
Tax included
Add to Cart
Share on

  • Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab standards
  • Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards
  • Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE
  • A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof



Manufacturer Website:
https://www.dahuasecurity.com/products/All-Products/Transmission/Cloud-Managed-Switches/CS4010-8GT-110

Category Code
SWI
CnCode
85176200
Unit Box Height
0.09
Unit Box Length
0.255
Unit Box Width
0.245
Cloud-managed
Yes
Quality of Service (QoS) support
Yes
Switch layer
L2
Switch type
Managed
Web-based management
Yes
Basic switching RJ-45 Ethernet ports quantity
10
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
10
10G support
No
Copper ethernet cabling technology
1000BASE-T/100BASE-TX/10BASE-T
Ethernet LAN data rates
10,100,1000 Mbit/s
Flow control support
Yes
Networking standards
IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x
Number of VLANs
32
Spanning tree protocol
Yes
Virtual LAN features
Port-based VLAN
VLAN support
Yes
Forwarding rate
4.17 Mpps
Jumbo frames
15000
Jumbo frames support
Yes
MAC address table
8000 entries
Packet buffer memory
0.5 MB
Switching capacity
20 Gbit/s
DHCP features
DHCP client
Housing material
Metal
LED indicators
Yes
Product colour
Black
Rack mounting
No
Reset button
Yes
DC input voltage
54 V
Input current
2.22 A
Power consumption (max)
110 W
Power source
DC/PoE
Power supply included
Yes
Redundant power supply (RPS) support
Yes
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
8
Operating relative humidity (H-H)
5 - 95 %
Operating temperature (T-T)
-10 - 55 °C
Storage relative humidity (H-H)
5 - 95 %
Storage temperature (T-T)
-40 - 70 °C
Depth
106 mm
Height
30 mm
Weight
550 g
Width
190 mm
Package depth
244 mm
Package height
87 mm
Package weight
1300 g
Package width
256 mm
Sustainability compliance
Yes
Compliance certificates
CE
Model name
CS4010-8GT-110
Units per Shipping Box
1
Unit Calculated Volume
0.005623 cubm
Unit Calculated Weight
1.28 kg
Category Switche Brand DAHUA EAN13 6923172571151 In stock 29 Items
