Ubiquiti UXG-Lite-EU Gateway UniFi
€134.33
A 48-port, Layer 2 PoE switch with a silent, fanless cooling system.
- (32) GbE, PoE+ RJ45 ports
- (16) GbE RJ45 ports
- (4) 1G SFP ports
- 195W total PoE availability
- 1.3" LCM color touchscreen with AR switch management
Manufacturer Website:
https://store.ui.com/collections/unifi-network-switching/products/usw-48-poe
- Category Code
- SWI
- CnCode
- 85176200
- Unit Box Height
- 0.43
- Unit Box Length
- 0.54
- Unit Box Width
- 0.13
- Switch layer
- L2
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 48
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- SFP module slots quantity
- 4
- 10G support
- No
- Auto MDI/MDI-X
- Yes
- Auto-sensing
- Yes
- Flow control support
- Yes
- Link aggregation
- Yes
- Networking standards
- IEEE 802.1x/IEEE 802.3af/IEEE 802.3at
- Port mirroring
- Yes
- Spanning tree protocol
- Yes
- VLAN support
- Yes
- Forwarding rate
- 77.38 Mpps
- Jumbo frames support
- Yes
- Switching capacity
- 104 Gbit/s
- Throughput
- 52 Gbit/s
- Authentication type
- RADIUS
- Form factor
- 1U
- LED indicators
- Activity/Link/Speed
- Product colour
- Stainless steel
- Rack mounting
- Yes
- Fanless
- Yes
- AC input frequency
- 50 - 60 Hz
- AC input voltage
- 100 - 240 V
- Power consumption (max)
- 45 W
- Power source
- AC/DC
- Power supply included
- Yes
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet (PoE) power per port
- 32 W
- Power over Ethernet plus (PoE+) ports quantity
- 32
- Total Power over Ethernet (PoE) budget
- 195 W
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- -5 - 40 °C
- Depth
- 285 mm
- Height
- 43.7 mm
- Weight
- 4520 g
- Width
- 442.4 mm
- Manual
- Yes
- Certification
- CE, FCC, IC
- Model name
- USW-48-POE
- Units per Shipping Box
- 2
- Unit Calculated Volume
- 0.03019 cubm
- Unit Calculated Weight
- 6.28 kg
