The mAP (micro Access Point) is a tiny size wireless Dual-Chain 2.4GHz Access Point with full RouterOS capabilities. It is very portable, since it accepts power from a wide variety of sources - USB, Passive PoE and power jack. It also works as a PoE injector - the second Ethernet port provides up to 500mA of power to another device, for example, you can connect a SXT CPE device to it.
Manufacturer Website:
https://mikrotik.com/product/RBmAP2nD
- Category Code
- WAP
- CnCode
- 85176200
- Unit Box Height
- 0.055
- Unit Box Length
- 0.175
- Unit Box Width
- 0.075
- 2.4 GHz
- Yes
- 5 GHz
- No
- Auto MDI/MDI-X
- Yes
- Ethernet LAN data rates
- 10/100 Mbit/s
- Networking standards
- IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3af/IEEE 802.3at
- DC-in jack
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- USB 2.0 ports quantity
- 1
- USB connector type
- USB Type-B
- Output current
- 0.8 A
- Output voltage
- 24 V
- Power over Ethernet (PoE)
- Yes
- Internal
- No
- LED indicators
- Yes
- Placement
- Table
- Product colour
- Black/White
- Antenna gain level (max)
- 1.2 dBi
- Built-in processor
- Yes
- Flash memory
- 16 MB
- Internal memory
- 64 MB
- Operating system installed
- Linux
- Depth
- 68 mm
- Height
- 19 mm
- Width
- 68 mm
- AC adapter included
- Yes
- Cables included
- USB
- Operating relative humidity (H-H)
- -10 - 70 %
- Harmonized System (HS) code
- 85176990
- Model name
- mAP // RBmAP2nD
- Units per Shipping Box
- 20
- Unit Calculated Volume
- 0.001057 cubm
- Unit Calculated Weight
- 0.267 kg
