- SKU
- KBASUAA8B850A02
- Barcode
- 4711387769300
- Model
- ROG STRIX B850-E GAMING WIFI
- CPU socket
- Socket AM5
- Processor family
- AMD Ryzen 7
- Processor family
- AMD Ryzen 9
- Processor family
- AMD Ryzen 5
- Integrated CPU
- No
- Chipset manufacturer
- AMD
- Chipset type
- AMD B850 Chipset
- Memory type
- DDR5
- Number of DDR5 slots
- 4
- Memory bus frequency
- 8000 MHz
- Max memory size
- 192
- Expansion slots
- 1 x PCIe 4.0 x 16
- Expansion slots
- 2 x PCIe 5.0 x16
- Expansion slots
- 5 x M.2
- Max. number of SATA devices
- 4
- RAID
- Yes
- Detailed data on disk/drive interfaces
- AMD Ryzen 9000 & 7000 Series Desktop ProcessorsM.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)*M.2_3 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)*AMD Ryzen 8000 Series Desktop ProcessorsM.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280/22110 (Not supports)**M.2_3 slot (Key M), type 2280 (Not supports)***AMD B850 ChipsetM.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)***M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)4 x SATA 6Gb/s portsAMD RAIDXpert2 TechnologyRyzen 9000 Series Processors: RAID 0/1/5/10Ryzen 8000 Series Processors: RAID 0/1Ryzen 7000 Series Processors: RAID 0/1/10
- Graphics
- 1 x DisplayPort* 1 x HDMI port** 1 x USB4 (40 Gbps) port supports USB Type-C display output*** * Supports up to 8K@30Hz as per DisplayPort 1.4 specification** Supports 4K@60Hz as per HDMI 2.1 specification*** Supports up to 4K@60Hz as per DisplayPort 1.4a specification***** VGA resolution support depends on processor or graphics card resolution.
- Sound card
- ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080* Impedance sensing for front and rear headphone outputs Supports: jack detection, streaming, and front-panel microphone jack remapping High-quality stereo playback output with a SNR of 120 dB and recording input with a SNR of 110 dB Supports playback up to 32-bit/384 kHz on the front panel Audio Features SupremeFX Shielding Technology Savitech SV3H712 Amplifier Gold-plated audio jacks Rear optical S/PDIF output Premium audio capacitors Audio Shield
- Network interface
- 1 x 10/100/1000/2500/5000 Mbit/s
- Network interface
- Wi-Fi 802.11a/b/g/n/ac/ax/be
- Network interface
- Bluetooth
- Network interface
- Ethernet 1 x Realtek 5Gb Ethernet ASUS LANGuard Wireless and Bluetooth Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6 GHz frequency bands** Supports Wi-Fi 7 320 MHz band, up to 6.5 Gbps transfer speeds. Bluetooth v5.4
- USB ports at back panel
- 12
- USB ports on motherboard
- 7
- Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
- 1
- Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
- 9
- FireWire (IEEE 1394)
- No
- COM connector / port
- No
- LPT connector / port
- No
- External connectors
- 6 x USB 3.2 Gen 2 Type-A
- External connectors
- 1 x USB 3.2 Gen 2x2 Type-C
- External connectors
- 1 x USB4 Type-C
- External connectors
- 1 x Przycisk Clear CMOS
- External connectors
- 1 x Flash BIOS Button
- External connectors
- 1 x DisplayPort
- External connectors
- 1 x HDMI
- External connectors
- 1 x Line Out
- External connectors
- 1 x MIC
- External connectors
- 1 x RJ-45
- External connectors
- 1 x S/PDIF
- External connectors
- 1 x Wi-Fi Module
- External connectors
- 4 x USB 2.0
- Onboard connectors
- 3 x Addressable LED
- Onboard connectors
- 1 x Thermal sensor connector
- Onboard connectors
- 1x CPU/DRAM overvoltage jumper
- Onboard connectors
- 2 x USB 2.0/1.1 header
- Onboard connectors
- 1 x USB 3.2 Gen 1 Type-A
- Onboard connectors
- 1 x USB 3.2 Gen 2 Type-C
- Onboard connectors
- 1 x System panel header
- Onboard connectors
- 4 x SATA III 6Gb/s
- Onboard connectors
- 1 x 4pin CPU fan
- Onboard connectors
- 1 x 4pin wentylator OPT CPU
- Onboard connectors
- 5 x 4pin Chassis fan
- Onboard connectors
- 1 x 4-pin water-pump-fan
- Onboard connectors
- 2 x 8pin 12V
- Onboard connectors
- 1 x 24pin ATX zasilanie
- Onboard connectors
- 1 x Front panel audio header
- Onboard connectors
- 1 x Power button
- Onboard connectors
- 5 x M.2
- Form factor
- ATX
- Dimensions
- 30.5 cm x 24.4 cm
- Accessories included
- 2 x SATA 6Gb/s Cable M.2 22110 Thermal Pad ASUS WiFi Q-Antenna Cable Tie Pack M.2 Q-Slide Pack ROG Keychain ROG Strix Stickers 5 x M.2 Rubber Bands Quick Start Guide
- Supported operating systems
- Windows 11
- Software
- ROG-exclusive software- ROG CPU-Z- Dolby AtmosASUS-exclusive softwareArmoury Crate- AIDA64 Extreme (60-day free trial)- Aura Creator- Aura Sync- GameFirst- Fan Xpert 4- HWiNFO- Power SavingASUS DriverHubASUS GlideXUSB Wattage WatcherTurboV CoreAdobe Creative Cloud (free trial)Norton 360 for Gamers (60-day free trial)WinRAR (40-day free trial)UEFI BIOSAI Overclocking GuideASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ Mode- ASUS MyHotkeyDynamic OC SwitcherCore Flex
- Other information
- WOL management via PME, PXE
- Designation
- CE+WEEE
