Tp-Link Access Point|TP-LINK|22000 Mbps|IEEE 802.11a/b/g|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|2x10GbE|EAP783

SKU EAP783 Category Access points
Price: €828.84
Tax included
Share on

Multi-Link Operation (MLO)
Enables devices to simultaneously send and receive data across different frequency bands and channels.

Two 10G PoE++ Ports
Boosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.

Auto Channel Selection and Power Adjustment
Boost WiFi performance and minimize interference for your network.

Intelligent Power Management
Offers more reliable network operation for your business.

Centralized Cloud Management
Manage the whole network locally or from the cloud.

Omada Mesh Technology
More flexible and convenient wireless deployment.△

PoE++ Power
Supports both 12V DC and 802.3bt PoE++ for flexible installations.

  • BE19000 Tri-Band Wi-Fi 7: 11520 Mbps (6 GHz) + 5760 Mbps (5 GHz) + 1376 Mbps (2.4 GHz). Buffering will no longer be a problem
  • Clear 6 GHz Band: Brings cleaner and wider band resources to your Wi-Fi
  • 2× 10G Port: Unlock the full potential of Wi-Fi 7
  • 320 MHz Bandwidth: Up to 320 MHz bandwidth enables many more simultaneous transmissions at the fastest possible speeds
  • Low Latency and Interference: Multi-Link Operation, and Multi-RUs ensure high performance of your network
  • Advanced Functions:Supports centralized management, mesh, and seamless roaming



Manufacturer Website:
https://www.tp-link.com/sg/business-networking/omada-sdn-access-point/eap783/#overview

Category Code
WAP
CnCode
85176200
Unit Box Height
0.095
Unit Box Length
0.355
Unit Box Width
0.325
2.4 GHz
Yes
5 GHz
Yes
6 GHz
Yes
Airtime Fairness (ATF)
Yes
Automatic channel scanning
Yes
Automatic channel selection
Yes
Band steering
Yes
BeamForming
Yes
Ethernet LAN data rates
10000 Mbit/s
Flow control support
Yes
Frequency band
2.4 - 6 GHz
Maximum data transfer rate
19000 Mbit/s
Maximum data transfer rate (2.4 GHz)
1376 Mbit/s
Maximum data transfer rate (5 GHz)
5760 Mbit/s
Maximum data transfer rate (6 GHz)
11520 Mbit/s
MIMO
Yes
MIMO type
Multi User MIMO
Networking standards
IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11be/IEEE 802.11g/IEEE 802.11n
Number of users
760 user(s)
Quality of Service (QoS) support
Yes
Rate limiting
Yes
VLAN support
Yes
Access Control List (ACL)
Yes
Security algorithms
WPA/WPA2/WPA3
DC-in jack
Yes
Ethernet LAN (RJ-45) ports
2
DC voltage range
12 V
Power over Ethernet (PoE)
Yes
LED indicators
Yes
Placement
Ceiling,Wall
Product colour
White
Reset button
Yes
Antenna type
Internal
Depth
280 mm
Height
46.5 mm
Width
280 mm
Package type
Box
Mounting kit
Yes
Quantity per pack
1 pc(s)
Quick start guide
Yes
Operating relative humidity (H-H)
10 - 90 %
Operating temperature (T-T)
0 - 40 °C
Storage relative humidity (H-H)
5 - 90 %
Storage temperature (T-T)
-40 - 70 °C
Model name
BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
Units per Shipping Box
1
Unit Calculated Volume
0.01096 cubm
Unit Calculated Weight
2.5 kg
Category Access points Brand TP-LINK EAN13 4895252503517 In stock 4 Items
