3x M.2M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devicesM.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devicesM.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices4x SATA 6G
Graphics
1x HDMI HDMITM 2.1 support with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort DP 1.4 support, maximum resolution of 8K 60Hz*. *Only available for processors with integrated graphics. Graphics specifications may vary depending on the processor installed.
Sound card
Realtek ALC897 codec 7.1 channel high performance USB audio Supports S/PDIF output
Network interface
1 x 10/100/1000/2500 Mbit/s
Network interface
Realtek 2.5 Gbps LAN WIRELESS / BLUETOOTH Intel Wi-Fi 6E Wireless module is pre-installed in M.2 slot (Key-E). Supports MU-MIMO TX/RX, 2.4 GHz / 5 GHz / 6 GHz* (160 MHz) up to 2.4 Gbps Supports 802.11 a/b/g/n/ac/ax Supports Bluetooth 5.3, FIPS, FISMA * 6E 6GHz Wi-Fi may depend on regulations in each country and will be ready on Windows 11. ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
USB ports at back panel
9
USB ports on motherboard
7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports
2
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports
6
FireWire (IEEE 1394)
No
COM connector / port
No
LPT connector / port
No
External connectors
1 x DisplayPort
External connectors
1 x Side Speaker
External connectors
1 x Rear Speaker
External connectors
1 x RJ-45
External connectors
1 x S/PDIF
External connectors
4 x USB 2.0
External connectors
1 x HDMI
External connectors
1 x USB 3.1 Type-C
External connectors
4 x USB 3.1
Onboard connectors
2 x System panel header
Onboard connectors
1 x 24pin ATX zasilanie
Onboard connectors
4 x USB 2.0/1.1
Onboard connectors
2 x USB 3.0 header
Onboard connectors
1 x USB C
Onboard connectors
1 x TPM header
Onboard connectors
2 x 4pin wentylator CPU
Onboard connectors
1 x 4pin CPU/Water Pump Fan Connector
Onboard connectors
2 x RGB LED Strip
Onboard connectors
1 x Front panel audio header
Form factor
ATX
Dimensions
243.84 x 304.8 mm
Accessories included
Quick Installation Guide SATA cable EZ M.2 clip Cable stickers WiFi antenna European Union regulatory notice
