Dahua NET CAMERA 5MP EYEBALL/HDW5559TM-ASE-IL-0360B DAHUA
Price:
€308.99
Tax included
Product Comments module (productcomments) must be installed!
Share on
- 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
- Outputs max. 5 MP (2960 × 1668) @25/30 fps.
- Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m.
- ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions.
- With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc.
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card; built-in Mic
- 12 VDC/PoE power supply; ePoE
- IP67 protection.
Manufacturer Website:
https://www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-5-Series/Smart-Dual-Light/5MP/IPC-HDW5559TM-ASE-IL
- Category Code
- FNC
- CnCode
- 85258900
- Unit Box Height
- 0.14
- Unit Box Length
- 0.14
- Unit Box Width
- 0.15
- Form factor
- Turret
- Housing material
- Metal
- International Protection (IP) code
- IP67
- Mounting type
- Ceiling
- Product colour
- White
- Alarm input/output
- Yes
- Connectivity technology
- Wired
- Day/night mode
- Yes
- Dynamic range
- 56 dB
- People counting function
- Yes
- Placement supported
- Outdoor
- Type
- IP security camera
- Wide Dynamic Range (WDR)
- Yes
- Angle of rotation
- 360 °
- Camera pan control
- Yes
- Camera shutter speed
- 1/3 - 1/100000 s
- Camera shutter type
- Electronic
- Camera tilt control
- Yes
- Lens viewing angle, diagonal
- 127.1 °
- Lens viewing angle, horizontal
- 108.4 °
- Lens viewing angle, vertical
- 60 °
- Minimum illumination
- 0.0005 lx
- Pan range
- 0 - 360 °
- Tilt angle range
- 0 - 80 °
- White balance
- Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
- Optical sensor size
- 1/2.7 "
- Progressive scan
- Yes
- Sensor type
- CMOS
- Closest focusing distance
- 3.2 m
- Detect distance
- 124 m
- Fixed focus
- Yes
- Focal length range
- 6 - 2.8 mm
- Identify distance
- 12.4 m
- Maximum aperture number
- 1.6
- Observe distance
- 49.6 m
- Recognize distance
- 24.8 m
- LED type
- IR/White
- Night vision
- Yes
- Night vision distance
- 50 m
- Back Light Compensation (BLC)
- Yes
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Frame rate
- 30 fps
- Gain control type
- Auto/Manual
- Highlight Compensation (HLC)
- Yes
- Maximum resolution
- 2960 x 1668 pixels
- Noise reduction
- Yes
- Noise reduction technology
- 3D noise reduction
- Privacy masking
- Yes
- Region of Interest (ROI) encoding
- Yes
- Total megapixels
- 5 MP
- Video compression formats
- H.264/H.264B/H.264H/H.265/M-JPEG
- Video streaming
- Yes
- Audio formats supported
- G.711 µ-law/G.711 A-law/G.723/G.726/PCM
- Audio input channels
- 1.0 channels
- Audio output channels
- 1.0 channels
- Built-in microphone
- Yes
- Bluetooth
- No
- Ethernet LAN
- Yes
- Number of users
- 20 user(s)
- Quality of Service (QoS) support
- Yes
- Streaming method
- Multicast
- Supported network protocols
- IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Registration
- Wi-Fi
- No
- Built-in HDD
- No
- Card reader integrated
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 1000 GB
- RAM capacity
- 2000 MB
- ROM capacity
- 4000 MB
- Ethernet LAN (RJ-45) ports
- 1
- Alarm input channels
- 1
- Alarm output channels
- 1
- Digital watermark
- Yes
- HTTPS encryption
- Yes
- Human and vehicle targets classification
- Yes
- Intelligent Video Surveillance (IVS) system features
- Face detection/Heat map/Human detection/Intrusion/People counting/Tripwire
- Mirror
- Yes
- Network access storage (NAS)
- Yes
- Video motion detection
- Yes
- Cloud-managed
- No
- DC output voltage
- 12
- Power consumption (max)
- 13.3 W
- Power consumption (Power over Ethernet (PoE))
- 6.3 W
- Power consumption (typical)
- 4.2 W
- Power source type
- DC,PoE
- Operating relative humidity (H-H)
- 0 - 95 %
- Operating temperature (T-T)
- -40 - 60 °C
- Storage temperature (T-T)
- -40 - 60 °C
- Mobile operating systems supported
- Android/iOS
- Diameter
- 122 mm
- Height
- 105.5 mm
- Weight
- 530 g
- Compliance certificates
- CE/Electromagnetic Compatibility (EMC)
- Package type
- Box
- Package weight
- 710 g
- Manual
- Yes
- Number of cameras
- 1
- Audio input
- RCA
- Audio output
- RCA
- Browser supported
- IE: IE 11, Chrome: Chrome 102, Firefox: Firefox 88
- Lens mount interface
- M12
- Number of video streams
- 4
- Units per Shipping Box
- 1
- Unit Calculated Volume
- 0.00294 cubm
- Unit Calculated Weight
- 0.78 kg
