Dahua Switch|DAHUA|16xRJ-45 ports|SF1016L
Price:
€28.73
Tax included
Product Comments module (productcomments) must be installed!
Share on
The Device is a layer-2 commercial switch. It has a high-performance switching engine and a large buffer memory to ensure smooth video stream transmission. With a plastic and fanless design, the device provides a more cost-effective option for customers. The Device is an unmanaged switch, so it does not need to be configured through web interface, which simplifies installation.
- 16 × RJ-45 10/100 Mbps ports
- Wide operating temperature ranging from –10 °C to +55 °C
- Easy to install, and is plug and play
- Supports wall mount and desktop mount
Manufacturer Website:
https://transmission.dahuasecurity.com/en/product-list/Home/SOHOSwitches/PlasticSwitch/SF1016L
- Summary
- Dahua Technology SF1016L. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8 entries, Switching capacity: 3.2 Gbit/s. Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3. DC input voltage: 12 V. Form factor: Desktop/Wall-Mounting
- Category Code
- SWI
- CnCode
- 85176200
- Unit Box Height
- 0.175
- Unit Box Length
- 0.205
- Unit Box Width
- 0.09
- Switch layer
- L2
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Basic switching RJ-45 Ethernet ports type
- Fast Ethernet (10/100)
- 10G support
- No
- Ethernet LAN data rates
- 10,100 Mbit/s
- Networking standards
- IEEE 802.3/IEEE 802.3u/IEEE 802.3x
- Forwarding rate
- 2.38 Mpps
- Jumbo frames
- 1520
- Jumbo frames support
- Yes
- MAC address table
- 8 entries
- Switching capacity
- 3.2 Gbit/s
- Form factor
- Desktop/Wall-Mounting
- Product colour
- Grey
- DC input voltage
- 12 V
- Input current
- 0.5 A
- Power consumption (typical)
- 1.5 W
- Power source
- DC
- Storage relative humidity (H-H)
- 10 - 90 %
- Storage temperature (T-T)
- -40 - 60 °C
- Depth
- 120 mm
- Height
- 42 mm
- Weight
- 300 g
- Width
- 160 mm
- Package depth
- 180 mm
- Package height
- 92 mm
- Package weight
- 600 g
- Package width
- 207 mm
- Model
- SF1016L
- Units per Shipping Box
- 12
- Unit Calculated Volume
- 0.004615 cubm
- Unit Calculated Weight
- 0.675 kg
