Name: Asrock Motherboard B850I LIGHTNING WIFI AM5 2DDR5 ITX
Brand: ASROCK
SKU: B850I LIGHTNING WIFI
Price: 213.61 EUR
Availability: InStock

SKU B850I LIGHTNING WIFI Category Mainboards

€213.61

Tax included

Last items in stock

Share on

SKU: KBASRAA8B850M00
Barcode: 4711581490130
Model: B850I LIGHTNING WIFI
CPU socket: Socket AM5
Processor family: AMD Ryzen
Integrated CPU: No
Chipset manufacturer: AMD
Chipset type: AMD B850
Memory type: DDR5
Number of DDR5 slots: 2
Memory bus frequency: 8200 MHz
Max memory size: 128
Expansion slots: 1 x PCIe 5.0 x 16
Expansion slots: 1 x M.2
Max. number of SATA devices: 2
RAID: Yes
Detailed data on disk/drive interfaces: CPU: 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* Chipset: 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* 2 x SATA3 6.0 Gb/s Connectors
Graphics: Integrated AMD RDNA graphics (Actual support may vary by CPU) 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz 1 x USB 3.2 Gen2 Type-C, supports DP 1.4 HBR3 and max. resolution up to 4K 60Hz (DP-alt mode supports DP1.4a)
Sound card: 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) Impedance Sensing on Rear Out port Individual PCB Layers for R/L Audio Channel Nahimic Audio
Network interface: 1 x 10/100/1000/2500 Mbit/s
Network interface: Wi-Fi 802.11a/b/g/n/ac/ax/axe
Network interface: Bluetooth
Network interface: LAN: 2.5 Gigabit LAN 10/100/1000/2500 Mb/s Killer E3100G Supports Killer LAN Software Wireless LAN: 802.11axe Wi-Fi 6E Module Supports IEEE 802.11a/b/g/n/ac/ax/axe Supports Dual-Band 2x2 with extended 6GHz band support 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology Supports Bluetooth 5.2 Supports MU-MIMO
USB ports at back panel: 8
USB ports on motherboard: 5
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports: 4
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports: 3
FireWire (IEEE 1394): No
COM connector / port: No
LPT connector / port: No
External connectors: 2 x SMA
External connectors: 1 x HDMI
External connectors: 1 x Line Out
External connectors: 1 x MIC
External connectors: 1 x RJ-45
External connectors: 1 x S/PDIF
External connectors: 4 x USB 2.0
External connectors: 1 x USB 3.2 Gen 1 Type-A
External connectors: 2 x USB 3.2 Gen 2 Type-A
External connectors: 1 x USB 3.2 Gen 2 Type-C
External connectors: 1 x Flash BIOS Button
Onboard connectors: 1 x USB 3.2 Gen 1 Type-C
Onboard connectors: 1 x Thermistor Cable Header
Onboard connectors: 2 x Addressable LED
Onboard connectors: 2 x SATA III 6Gb/s
Onboard connectors: 2 x USB 2.0/1.1 header
Onboard connectors: 2 x USB 3.2 Gen 1 Type-A
Onboard connectors: 1 x 8pin 12V power
Onboard connectors: 1 x 4pin CPU fan
Onboard connectors: 1 x 4pin Chassis fan
Onboard connectors: 1 x 4-pin water-pump-fan
Onboard connectors: 1 x 24pin ATX zasilanie
Onboard connectors: 2 x M.2
Onboard connectors: 1 x Front panel audio header
BIOS: 256Mb AMI UEFI Legal BIOS with GUI support
Form factor: mini ITX
Dimensions: 17 x 17 cm
Accessories included: 2 x SATA Data Cables 2 x ASRock WiFi 2.4/5/6 GHz Antennas 2 x Screws for M.2 Sockets Thermistor Cable
Supported operating systems: Windows 10
Supported operating systems: Windows 11
Software: Software: ASRock Motherboard Utility (Phantom Gaming Tuning) Killer Control Center ASRock Polychrome SYNC UEFI: ASRock EZ Mode ASRock Full HD UEFI ASRock Auto Driver Installer ASRock Instant Flash
Designation: CE+WEEE
